Anritsu BTS Master MT8222B Base Station Analyzer
The Anritsu BTS Master MT8222B Base Station Analyzer has an ACPR that measures the amount of the carrier that gets into neighboring RF channels. ACPR and multi-channel ACPR check the nearest (adjacent) and second nearest (substitute) RF channels for single and multicarrier signals. High ACPR will create an obstruction for neighboring carriers. This is also a sign of low signal quality and low capacity, which can lead to blocked calls.
This instrument offers a Spectral Emission Mask (SEM) as a way to check out-of-channel spurious emanations close to the carrier. These spurious emanations both demonstrate contortion in the signal and can create obstruction with carriers in the adjoining channels. Issues leads to obstruction and accordingly, lower data rates, for nearby carriers. Faults additionally may lead to legitimate liability and low in-channel signal quality. In this model, Rho is a measure of adjustment quality. Rho Pilot, Rho Mac, and Rho Data are the essential signal quality tests for EV-DO base stations. Low Rho results in dropped calls, low signal quality, low data rate, low sector capacity, and blocked calls. This is the most vital signal quality estimation.
PN Code overlap is checked by the pilot scanner. An excessive number of strong pilots make pilot contamination, which results in a low information rate, low limit, and exorbitant delicate handoffs.
If you are interested in this model and you want to learn more about its specifications, features and special options, you can read its manual, which is available on the ApexWaves.com website.
| Model | MT8222B |
|---|---|
| Manufacturer | Anritsu Corporation (ã‚¢ãƒ³ãƒªãƒ„æ ªå¼ä¼šç¤¾ Anritsu Kabushiki-gaisha) |
| Series | BTS Master |
| Type | Base Station Analyzer |
| Cable & Antenna Analyzer | 400 MHz to 6.0 GHz |
| Spectrum Analyzer | 150 kHz to 7.1 GHz |
| Power Meter | 10 MHz to 7.1 GHz |
| Battery Life | 2.5 hours |
| MT8222B Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
