Anritsu Handheld Spectrum Analyzer MS2712E
Here comes MS2712E – another significant constituent of the Spectrum Master series from the house of Anritsu. The MS2712E is a powerful instrument. Its broad functionality, ease of use, and outstanding precision are a few most appreciated characteristics among the technical fraternity. The frequency range spans from 9 kHz to 4 GHz, the dynamic range is >95 dBm, and the phase noise at 10 kHz offset at 1 GHz is -100 dBc/Hz max. The MS2712E comes fully equipped with: an interference analyzer for RSSI, Signal ID, Interference Mapping, and more, indoor/outdoor coverage mapping, an ISDB-T signal analyzer, and single-button measurements for ACPR, Channel Power, Occupied Bandwidth, Field Strength, etc.
The MS2712E has several advanced features, such as: a save-on-event through which the instrument saves a sweep automatically when crossing a pre-defined limit line or at the end of the sweep and a Gated Sweep function, which is incorporated to view burst or pulsed signals when they are on or off.
As far as the physical appearance and designs characteristics are concerned, it is a fantastic machine. Rugged perfectly for outdoor operations, with an operating temperature range from -10 to 55 °C, the model weighs less than 3.45 kg. The MS2712E has a powerful 8.4" color display designed to provide clear visibility even in broad daylight.
| Model | MS2712E |
|---|---|
| Manufacturer | Anritsu |
| Series | Anritsu Handheld Spectrum Analyzers |
| Type | Handheld Spectrum Analyzer |
| Frequency | 9 kHz to 4 GHz |
| Dynamic Range | >102 dB |
| Display | 8.4 inch daylight viewable touchscreen |
| Battery Life | 3 hours max |
| MS2712E Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for MS2712E:
MS2712E Anritsu Handheld Spectrum Analyzer- FAQ:
Question:
On the MS2712E Handheld Spectrum Analyzer, what is the emission mask’s function?
Answer:
The emission mask shows frequency range, peak power and frequency, relative power and pass/fail status for each section of the mask. The emission mask has to have a minimum of two segments.
Question:
What is the frequency range for the MS2712E?
Answer:
The frequency range is 9 kHz to 4 GHz.
Question:
What is the operating temperature range for the MS2712E?
Answer:
The operating temperature range recommended is -10 to 55 degrees C.
