Anritsu Handheld Spectrum Analyzer MS2713E
Equipped with a High Accuracy Power Meter and capable of 2-Port Transmission Measurements, the MS2713E is another Compact Handheld Spectrum Analyzer model created by Anritsu. The MS2713E is a real multifunctional and multipurpose spectrum analyzer with the additional capabilities of an interference analyzer. Now, users can perform Interference Mapping measurements without employing another product. The most useful features of the MS2713E Handheld Spectrum Analyzer are: the four detection methods (Peak, RMS, Negative, Sample, Quasi-peak), a save on event function, a Gated Sweep Function, one-button measurements for ACPR and Field Strength, and USB support for data transfer.
The MS2713E is equipped with a comprehensive range of testing capabilities. This very instrument can be used for a variety of applications including but not limited to: CPRI RF Measurements, OBSAI RF Measurements, Coverage Mapping, Channel Scanning, and many other useful applications.
By design, the MS2713E is a sheer pleasure to work. Its long 3-hour battery backup, 8.4-inch color touchscreen display, easy controls, line sweep tools, and a comfortable weight makes this model a suitable choice for experts working in the field.
This unit tends to measure extremely small signals in the presence of relatively larger signals as its dynamic range is better than 102 dB in 1 Hz. It also has an impressive DANL performance as it comes with an incorporated pre-amp. This performance capability makes it an instrument of choice while dealing with low-level interference signals. In short, it is a simple machine with a lot of power.
| Model | MS2713E |
|---|---|
| Manufacturer | Anritsu |
| Series | Anritsu Spectrum Master |
| Type | Handheld Spectrum Analyzer |
| Frequency | 100 kHz to 6 GHz |
| Dynamic Range | >102 dB |
| Display | 8.4 inch daylight viewable touchscreen |
| Battery Life | 3 hours max |
| MS2713E Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for MS2713E:
MS2713E Anritsu Handheld Spectrum Analyzer- FAQ:
Question:
How large is the MS2713E?
Answer:
The MS2713E is 10.7 x 7.8 x 3.6 inches.
Question:
What type of measurement is the MS2713E best suited for?
Answer:
The MS2713E can make accurate measurements for: spectrum monitoring, interference analysis, broadcast proofing, Wi-Fi and wireless networks, and RF and microwaves.
Question:
What is the phase noise level for the MS2713E?
Answer:
The phase noise is -100 dBc/Hz max @ 10 kHz offset at 1 GHz.
Question:
Regarding the MS2713E, what types of sweep functions does it have?
Answer:
The MS2713E sweep functions are: single/continuous, sweep mode (fast, performance, no FFT), reset, minimum sweep time, trigger type, gated sweep, and detection.
