Anritsu Handheld Spectrum Analyzer MS2722C
The MS2722C Handheld Spectrum Analyzer designed by Anritsu is yet another high-performance handheld, lightweight and compact product in the Spectrum Master series created for 9 kHz to 9 GHz applications. This model, with its unique and powerful features, is best suited for a broad range of testing and analytical requirements like spectrum monitoring, RF/Microwave Measurements, Wireless Network Measurements, and Regulatory Compliance. A few of the unique features of the MS2722C include: ± 25 ppb Frequency Accuracy (with GPS On), >104 dB Dynamic Range (in 1 Hz RBW), -100 dBc/Hz Phase Noise at 1 GHz (@ 10 KHz offset), USB/Ethernet Data Transfer capabilities, and a Burst Detect and Channel Scanner.
The MS2722C features around 30 analyzers in one product to meet every measurement requirement. Not only this, but the user can also select and couple additional module compatible with the base MS2722C0. GPS Receiver, Fixed & Mobile WiMAX, and 3GPP/3GPP2 Signal Analyzers, to name a few.
For post analysis and processing of data collected and stored by your instrument, you can utilize Master Software Tools - a PC based program with powerful tools for interference monitoring and robust data analysis.
Working with this instrument`s frequency coverage band (9 kHz to 9 GHz) gives the wireless engineers and technicians the performance required for the most critical and demanding testing. Whether you are looking for hidden signal detection, microwave backhaul testing or RF signal measurements - the Spectrum Master MS2722C is the instrument designed to provide you with the tools required.
| Model | MS2722C |
|---|---|
| Manufacturer | Anritsu |
| Series | Anritsu Spectrum Master |
| Type | Handheld Spectrum Analyzer |
| Frequency | 9 kHz to 9 GHz |
| Dynamic Range | > 104 dB in 1 Hz RBW |
| Phase Noise | –100 dBc/Hz @ 10 kHz offset at 1 GHz |
| Resolution Bandwidth | 1 Hz to 10 MHz |
| MS2722C Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for MS2722C:
MS2722C Anritsu Spectrum Master- FAQ:
Question:
What type of display does the MS2722C have?
Answer:
The MS2722C has a bright, high-resolution LCD display, which can be easily viewed during the day.
Question:
How do I replace the battery on my MS2722C Spectrum Master?
Answer:
First, find the battery compartment on the lower left side. Next, slide the battery door down to take it off and take out the battery pack by tugging on the battery string. Place the new batteries inside.
Question:
Can the MS2722C be used while inside the soft carrying case?
Answer:
Yes, make sure the front panel of the case is completely closed. The front panel will hold up the shape of the case while you put the Spectrum Master inside. Make sure it is on a stable surface and open the zippered back of the case. Insert the instrument face down and ensure the connectors are situated correctly. Lastly, close the back panel and zip it back up.
