Anritsu MS8911A Digital Broadcast Field Analyzer
The MS8911A is a Digital Broadcast Field Analyzer that contains a 100 kHz to 7.1 GHz Spectrum Analyzer. This model is capable of supporting DVB-H and DVB-T estimations like field strength, modulation analysis, constellation, in-band interference, and impulse response. This analyzer is outfitted with different capacities like the settings of RBW, VBW, and span. The MS8911A can be utilized as an elite range analyzer in development and manufacturing.
This instrument incorporates a Spectrum Monitor, with a function that demonstrates the recurrence reaction around a specific channel. The span is variable, so up to 51 channels can be shown at the same time. With this capacity, the telecom benefit signals can be checked initially. In the field, there are many limitations on time, place, and the client's level of ability. The MS8911A gives simple operation with the goal that the amateur client can work this instrument by setting a specific channel number. Auto Reference Level and Detect Parameter options are utilized to set the reference level and transmission parameters consequently.
The MS8911A also has an Impulse Response Measurement capacity, which measures the distinction of time and level of the multi-way signals. By measuring the recurrence reaction of the channel, the impact of multi-way or recurrence specific blurring can be watched. This is helpful to alter timing of the SFN repeaters.
In case you are interested in this model and you want to know everything about its functions and different options, you can check the ApexWaves.com website where you will be able to find this model’s manual.
| Model | MS8911A |
|---|---|
| Manufacturer | Anritsu (Anritsu Kabushiki-gaisha) |
| Series | Spectrum Master Series |
| Type | Handheld Digital Broadcast Field Analyzer |
| Frequency Range | 100 kHz to 7.1 GHz |
| Maximum Input Level | + 43 dBm (20 W) |
| Dimensions | 313 x 211 x 77 mm |
| Sweep time | Minimum 100ms, 50 µs in zero span |
| MS8911A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
