Anritsu MS46322B Network Analyzer
Anritsu's MS46322B Network Analyzer is a multi-purpose tool that blends advanced vector network analysis into a compact form factor to meet the rigorous demands of RF and microwave tests. Taking advantage of cutting-edge ShockLine VNA-on-chip technology, it delivers two-port measurement capability in a power-efficient 2U package. The MS46322B is available with frequency ranges from 1 MHz to 8 GHz, 1 MHz to 20 GHz, and 1 MHz to 43.5 GHz, and is carefully crafted to deliver precise S-parameter and time domain measurements with unwavering reliability.
The instrument is designed on a modular base, which supports different calibration techniques, including Short-Open-Load-Through, SmartCal, and Precision AutoCal methods. The implemented correction algorithms, combined with advanced embedding and de-embedding techniques, provide accurate removal of the contribution of the test fixture, thus allowing correct passive component and complex network characterizations. In addition, the analyzer ensures measurement quality and dynamic range through the implementation of efficient measurement data protocols and a robust internal architecture that satisfies the high standards of the current industrial requirements.
Established on SCPI programming with industry standard LAN connectivity, the MS46322B supports remote control and seamless integration with automated tester systems. Touchscreen, keyboard, and mouse interfaces offer a simple graphical user interface for simple operation and real-time analysis. Front and rear panel USB, HDMI, and Ethernet connectivity and onboard CPU and solid-state drive that pop out add additional speed of processing as well as storage reliability for data.
The Anritsu MS46322B network analyzer is specially useful in the fields of telecommunications, the military, the aerospace industry, and other industrial fields because it has a wide range of functionalities that cover many testing requirements. Its measurement functions with high accuracy, efficient calibration techniques, and advanced de-embedding functions make it an essential instrument for technical professionals involved in the RF network measurement as well as microwave component measurement. Its lightweight and compact form, strong design, and universal connectivity ensure easy usage in both lab and field applications, thus making it indispensable gear in industrial automation testing.
| Model | MS46322B |
|---|---|
| Model Type | Vector Network Analyzer |
| Frequency Range | 1 MHz to 8 GHz / 1 MHz to 20 GHz / 1 MHz to 43.5 GHz |
| Dynamic Range | Up to 115 dB (Typical) |
| Measurement speed | 140 µs per Point (Typical) |
| Port Configuration | 2-Port, Bidirectional |
| Connectivity | LAN (SCPI Remote Control), USB 2.0 & 3.0 |
| Calibration Methods | SOLT, LRL, TRL, SSLT, SmartCal™, AutoCal™ |
| User Interface | Graphical UI |
| Interface Requirements | External Touchscreen, Keyboard, Mouse |
| Power Supply | 90–264 VAC, 47–63 Hz, 350 VA max |
