Fluke 1623 Geo Earth Ground Tester Kit
The Fluke 1623 Geo Earth Ground Tester Kit offers data storage and download competencies through a USB port. The world class accessories will simplify and accelerate testing time. This model has 3- and 4-pole fall of potential, earth resistance loop testing, 4-pole soil resistivity testing, selective earth ground rod testing using 1 clamp, a stakeless earth ground rod testing using 2 clamps, is IP56 rated for outdoor use, and has a USB data storage and transfer capability.
The Fluke 1623 can measure earth ground loop resistances utilizing only clamps. For this test method, two clamps are set around the earth ground rod and each are connected to the tester. No earth ground stakes are utilized. A known, altered voltage may be induced by one clamp and the current will be measured utilizing the second clamp. Then, the tester automatically determines the resistance of the earth ground rod. This test technique just meets expectations if a bonded earth ground framework exists to the building or structure under test, but most are. In case there is only one way to ground, like at many residential applications, the stakeless system will not give acceptable an acceptable value and the fall of potential test method must be utilized. With stakeless testing, the earth ground rod does not need to be disconnected, which leaves the bonded earth ground framework intact throughout the test.
If you are interested in this model and you want to learn more about its options, specifications, and special features, you can check its manual, which is available on the ApexWaves.com website.
| Model | Fluke 1623 |
|---|---|
| Manufacturer | Fluke |
| Type | Earth Ground Tester Kit |
| Measuring Time | Typical 6 seconds |
| Battery Life Span | Typical > 3,000 measurements |
| Weight | 1.1 kg (2.43 lb) including batteries |
| Memory | up to 1500 records accessible via USB port |
| Fluke 1623 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
