Fluke 1623-2 GEO Earth Ground Tester Kit
The 1623-2 is a GEO Earth Ground Tester Kit from Fluke. It is designed to offer accurate and fast earth ground tests by utilizing all four test methods. It also provides additional capabilities, such as data storage and downloads via USB port. This model can be used for 1 clamp based selective earth ground rod testing and 2 clamps based stakeless earth ground rod testing. With this instrument, the user can measure earth ground loop resistances with a mere set of clamps. The Fluke 1623-2 is a powerful instrument, which offers 3-pole and 4-pole fall of potential tests and 4-pole soil resistivity testing.
For displaying results, this model comes with an integrated 1999 digit LCD capable of displaying special symbols and clear digits at 25 mm. The Fluke 1623-2 GEO Earth Ground Tester Kit is quite a simple instrument with only two operating elements: a START button and a rotary switch. It is designed to offer instantaneous measurements through a one button concept. To store records for later studies, the user can take advantage of the internal memory where as many as 1500 records could be saved. The user can access this memory by employing a USB port.
The Fluke 1623-2 can measure interference voltage within a range of 1 V to 50 V and displays results at a resolution of 0.1 V. This model is capable of measuring interference frequency (F) in the 6.0 Hz to 400 Hz range. This instrument is designed in compliance with IP56 and can therefore be operated in harsh outdoor environments.
| Model | Fluke 1623-2 |
|---|---|
| Manufacturer | Fluke |
| Type | GEO Earth Ground Tester Kit |
| Internal Memory | 1500 records accessible via USB port |
| Measuring Time | 6 seconds approximately |
| Dimensions | 9.75 x 5.25 x 7.35 in. |
| Weight | 2.43 lb. with batteries |
| Fluke 1623-2 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
