Fluke Ti25 Infrared Camera
The Fluke Ti25 is well-suited for challenging work conditions and preventative upkeep, confirmation, and equipment troubleshooting. This handheld thermal imager can generate thermal and visual pictures on a 640 x 480 display screen. These pictures are then shown on the Imager LCD and can be stored to an SD Memory card. Moving pictures to a PC can be done by eradicating the SD memory card and linking it to a PC through the card reader included. SmartView software is also included for image assessment and report creation from the stored pictures. An additional feature on the Fluke Ti25, which is not available on the other thermal imagers, is the capability for voice recording for noting stored pictures. Voice comments are accessible for the user at any point in the future.
The images captured by the Fluke Ti25 Handheld Thermal Imager are clear enough for the user to spot issues quickly. There is also the added benefit of a hand strap, which can be altered to be utilized by right or left-handed users. The image frequency refresh rate is 9 Hz, the spatial resolution is 2.5 mRad, the detector type is 160 x 120 focal plane array, with a 20 mm F infrared lens type.
The menu is easy to navigate with only three softkeys for simplicity. These softkeys allow the user to alter settings, such as language, time, date, backlight, and spot temperatures. With the softkeys, the user can also store and look at pictures and the thermal image display.
| Model | Fluke Ti25 |
|---|---|
| Manufacturer | Fluke |
| Type | Infrared Camera |
| Spatial Resolution | 2.5 mRad |
| Minimum Focus Distance | Thermal lens: 15 cm (6 in); Visible (visual) light lens: 46 cm (18 in) |
| Image Frequency | 9 Hz refresh rate |
| Infrared Lens Type | 20 mm F = 0.8 lens |
| Fluke Ti25 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
