Keysight/Agilent P9374A Streamline USB Vector Network Analyzer
The P9374A Keysight Streamline USB Vector Network Analyzer (VNA) is a device that is capable of giving accurate RF measurements. It operates in a frequency range between 300 kHz and 20 GHz, making it an appropriate solution to a variety of RF and microwave testing applications. The model also has a USB 3.0 interface, allowing it to be persistently connected to a PC with either Windows 7 or Windows 10 (64-bit). This interface guarantees a rapid data transfer and fast communication with the analyzer. The minimum display resolution of the unit is 1024 x 768, which helps to form clear and detailed visuals of measurements. The VNA has two ports with many connector types, such as 3.5 mm, SMA, and SMB connector types.
The P9374A USB vector network analyzer has a dynamic range of more than 115 dB at 6.5 GHz with a 10 Hz IFBW. The low trace noise is less than 0.003 dBrms at 1 kHz IFBW, and it ensures stable results by improving the reliability of test results. The device shows a remarkable temperature stability of 0.005 dB/°C up to 4.5 GHz, which ensures accuracy across varying environmental conditions. This feature is especially beneficial for long-term testing and outdoor measurements where temperature fluctuations are common. The model delivers frequency resolution ranging from 1 to 6 Hz by allowing for precise detection of even the smallest signal changes. It is built for speed with a measurement time of just 24 ms by making it useful for testing.
The unit has a sweep speed of 14 ms, enabling efficient testing across wide frequency ranges. It excels in dynamic range by offering values between 95 and 122 dB for accurate readings. It has an adjustable output power ranging from 0 to 10 dBm for various test setups. The power sweep range spans from -40 to 7 dBm, and the noise floor varies from -108 to -98 dBm. The P9374A USB VNA comes with a directivity span between 31 and 52 dB. In terms of port impedance, it operates at 50 ohms, which is found to be a standard for many radio frequency domains.
| Model | P9374A |
|---|---|
| Manufacturer | Keysight/Agilent |
| Part Type | Keysight Streamline USB Vector Network Analyzer, 20 GHz |
| Interface Type | USB 3.0 |
| Frequency Resolution | 1 to 6 Hz |
| Frequency Range | 300 kHz to 20 GHz |
| Measurement speed | 24 ms |
| Sweep speed | 14 ms |
| Output Power | 0 to 10 dBm |
| Port Impedance | 50 Ohms |
