Anritsu MF2413C Microwave Frequency Counter
The MF2413C is an efficient microwave frequency counter from Anritsu. The instrument comes with two input channels. This model has a frequency range from 600 MHz to 27 GHz for input channel 1. The frequency range for input channel 2 is 10 MHz to 1 GHz at the impedance level of 50 Ohms. It is 10 Hz to 10 MHz at the impedance level of 1 mega-ohms. The Anritsu MF2413C also incorporates a high-quality VFD display on the front panel. The MF2413C microwave frequency counter offers a wide range of applications. This model has the capability to measure the carrier frequency and pulse width of burst signals. The user can also evaluate the integrity of different devices and circuits related to the mobile radio communications systems.
The Anritsu MF2413C microwave frequency counter has a gating function for the measurement of any burst section. The user can also carry out the pass or fail evaluation for a given frequency range, which is specified with the help of the template function. The instrument comes with different types of connector interfaces for the input channels. These connectors are SMA-type and BNC-type for input channels 1 and 2 respectively.
There are also internal or external trigger modes. The value for trigger level voltage is up to 1.5 volts. The trigger pulse width is greater than 1 microseconds. The Anritsu MF2413C microwave frequency counter offers high measurement accuracy. It comes with the capability to offer a gate width of 100 ns to 0.1 seconds. The time range for narrow pulse width is 100 ns to 0.1 seconds.
| Model | MF2413C |
|---|---|
| Manufacturer | Anritsu |
| Type | Microwave Frequency Counter |
| Frequency Range | 600 MHz to 27 GHz |
| Connectors | SMA and BNC type |
| Dimensions | 213 (W) x 88 (H) x 350 (D) mm |
| MF2413C Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
