Chroma ADLINK PXI 52981 I/O Module
The Chroma ADLINK 52981 PXI I/O Module can be integrated into modular automated test systems. As a collaborative product line, it represents a portion of the joint development of products from Chroma and ADLINK. It serves as a component of the PXI Platform. The PXI Platform is the industry standard for modular automated test equipment (ATE) and this model will operate inside a PXI chassis and will be utilized in conjunction with additional instruments like the Chroma 58183E to create a customized test solution that can accommodate a variety of industrial applications.
As a PXI module, the 52981 has been engineered for high performance and system scalability. The architecture of the PXI platform enables synchronization of multiple modules and chassis; this allows engineers to expand their test systems as the requirements of their systems evolve. The typical application for the I/O Module would be to interface with a Unit Under Test (UUT); the UUT would utilize the digital/analog I/O of the module as the input and output of signals as defined by the test protocol. The design of the module emphasizes precision and tight integration with other components of the system to produce high measurement accuracy and repeatability; both of these characteristics are important in production environments in order to maintain yield integrity.
The application areas for the Chroma ADLINK 52981 align closely with the areas of application for PXI-based systems from ADLINK, which are deployed in demanding applications including, but not limited to, the semiconductor manufacturing industry, the telecommunications industry, the automotive industry, and the data center testing industry. Within the semiconductor test industry, for example, PXI-based systems can provide greater test density and more efficient testing in a smaller footprint. In automotive applications, particularly those related to electric vehicles (EVs), such as HIL and real-time validation systems, this type of module can also be a part of the overall system. Through the use of the PXI standard, the 52981 I/O module provides a future-proofed solution to meet the demands of increasingly complex automated test procedures.
| Model | ADLINK 52981 |
|---|---|
| Part Type | PXI Module |
| Form Factor | 3U PXIe |
| Slot Requirement | Single Slot |
| Bus Interface | PXI Express |
| Processor | Multicore CPU |
| Programmable Logic | FPGA |
| Synchronization | PXI Trigger Bus & Star Trigger |
| Operating Temperature | 0 to 55 °C |
| Software Support | LabVIEW, MATLAB |
