Keithley 2400 SourceMeter Instrument
The Keithley 2400 Source Meter is a universal tool that combines high voltage and current sourcing capability with high measurement capability. This tool is suitable for use by research laboratories and by industrial automation, where the DC power source is coupled together with the features of an integrated 6½-digit multimeter. This combination creates the ability for the execution of high DC parametric tests simultaneously by sourcing voltage or current and also by measuring high-resolution electrical parameters. This tool’s small form allows for easier integration into automated test equipment and manufacturing test floorspace, shortening set-up times and eliminating complicated measurement processes.
Engineered with measurement and source circuits close together, the 2400 Source Meter reduces the delays and synchronization involved when utilizing multiple tools. Having the capability of being able to work as a voltage or current source, voltage or current meter, and ohmmeter, the double capability creates the ability for multiple functions. This is very beneficial when utilizing the tool for the characterization of semiconductors, where high-resolution measurements for the I-V and the extraction for the device parameters need to be accomplished. Integrated features such as custom sweeping functions, contact check capability, and test sequencing make its operation even more superior for automated test applications.
The 2400 Source Meter also has superior six-wire and four-wire measurement and superior remote sensing, delivering measurements under the harshest test conditions. A friendly operator interface accommodates common communication protocols, automated test set-ups and data gathering equipment for simplified integration. This tool has also been designed for efficiency, keeping the GPIB traffic low and delivering high measurement cycle speeds. This tool can also be applied from the component test level through the circuit analysis level by its flexibility. With its robustness and range of features, the Keithley 2400 Source Meter is the tool for the engineer willing to improve the test environment and efficiency for many industrial and research applications.
Engineered with high degrees of flexibility and precision, the tool is ready for the high demands of modern automated test stations and is designed for complex measurement methods. Integration into manufacturing processes ensures increased product quality and process reliability. The Keithley 2400 Source Meter is the best when the subject is precision and efficiency, empowering engineers with the capacity for detailed analysis of the electrical circuit with certainty and efficiency.
| Model | Keithley 2400 |
|---|---|
| Model Type | Source Meter (SMU) |
| Voltage Range | 200 mV to 200 V |
| Current Range | 1 µA to 1 A |
| Power Output | 20 W Max |
| Resolution | 6½-Digit |
| Quadrants | Four-Quadrant Operation |
| Compliance Limits | Programmable |
| Interfaces | GPIB, RS-232, Trigger Link |
| Measurement Speed | Up to 1700 readings/sec |
