Aeroflex - RF Digitizers - Aeroflex 3035
Aeroflex - RF Digitizers - Aeroflex 3035 - Wiring
Aeroflex 3035 New
Aeroflex 3035 Refurbished

✔ 2 Year Warranty Included

✔ Free Domestic Ground Shipping

✔ NIST Calibration Available

Get Price & Availability for the Aeroflex 3035

Fast response from an Apex Waves specialist.

Fast Response Avg. 15 min
ISO 9001 Quality 2 Year Warranty
In Stock Ships in 5-10 Days

Aeroflex 3035 PXI Wideband RF Digitizer

The Aeroflex 3035 is a precise PXI RF digitizer designed for use with RF automated environments within telecommunication applications. The design supports deterministic signal capture and accurate parameter control. It runs across a wide frequency band that ranges from 330 MHz to 6 GHz. The 3035 module includes a 36 MHz wide digitized bandwidth that supports controlled acquisition tasks. The digitizer also accepts a direct IF input centered at 77.76 MHz with a maximum input level of +10 dBm. The internal architecture supports precision measurements that maintain consistency across valid operating limits.

The level accuracy of the Aeroflex 3035 is specified within ±0.45 dB under defined environmental conditions. The accuracy value further reaches 0.3 dB for narrowband signals that meet the stated bandwidth and SNR requirements. Signals with occupied bandwidth above 5 MHz introduce an additional ±0.15 dB error that remains predictable under stable ADC clock conditions. The ADC clock operates at 103.68 MHz and supports consistent sampling control. The Aeroflex digitizer also supports dwell period entries that are expressed in output samples. The module contains 128 list addresses numbered from 0 to 127 for structured sequencing tasks.

The address control supports manual selection through software control or external switching through hardware triggers. The 3035 also includes an internal counter timer source that provides deterministic sequencing when external control is not required. Settling time behavior references the defined frequency and level data to ensure consistent transition performance. The design allows stable switching where repeatable timing is required. The sample rate resolution achieves 0.1 Hz and accepts fractional entries with a 32-bit numerator and denominator. The RF digitizer follows a 33 MHz bandwidth limit that defines operational boundaries. Channel filter alpha values range from 0 to 1 to support controlled measurement shaping. The Aeroflex 3035 system supports channel spacing up to 15 MHz and channel widths up to 25 MHz. These parameters enable structured analysis of modulated signals that fall within supported conditions. The controlled feature set ensures predictable measurement results in integrated PXI platforms.

ModelAeroflex 3035
ManufacturerAeroflex
Part TypePXI Wideband RF Digitizer
Maximum IF Power Input Level+10 dBm
Digitized Bandwidth36 MHz wide
Frequency Range330 MHz to 6 GHz
Required SNR for AccuracyHigher than 40 dB
ADC Clock Frequency103.68 MHz
List Mode ParametersFrequency, level, dwell period
Sample Rate Resolution0.1 Hz

Associated part numbers for Aeroflex 3035:
