Ballard Technology OmniBus MIL-STD-1553 CompactPCI/PXI Module
The OmniBus MIL-STD-1553 module (Part Number: 121-540) is a cPCI (3U) 1 Core module with CH) Level C functionality. This CompactPCI/PXI Module empowers PCs and systems to interface with numerous databases for testing, approving and reenacting business and military flight hardware and frameworks. These flexible units can be controlled through Ethernet or USB or can be customized to work independent. Promptly accessible as Commercial Off-The-Shelf items, this module is ideal for testing reproduction, test, interface, crossing over, control, recreation and information recording applications.
With the use of this module, clients can confirm wave frame compatibilities, test elements of transport shorts and opens, and—when joined with CoPilot® programming—perform lab generation and flight test check. This software is the best choice for OmniBus devices because it has the capability to host several databuses, cards, and channels. It can also be used effortlessly with Windows. Another choice is for the user to create their own customized software with the use of the BTIDriver API. The included library has a wide variety of features for many types of requirements.
Since this is a Level C product, the Ballard Technology OmniBus MIL-STD-1553 module has 32 simultaneous terminals, programmable bus termination, protocol error injection, filtering for terminal address, concurrent terminal monitoring, and filtering for subaddress. Other features of the OmniBus MIL-STD-1553 module include: a programmable onboard PowerPC processor, protocol processing, support for all 1553 message types, the simulation of several terminals, and the capability to alter the waveform.
| Model | OmniBus MIL-STD-1553 |
|---|---|
| Manufacturer | Ballard Technology |
| Part Number | 121-540 |
| Type | CompactPCI/PXI Module |
| Number of Cores | 1 |
| Level of Functionality | C |
| Dimensions | 3U x 4HP (Single Slot, Standard) |
| Weight | 5.3 oz. |
| OmniBus MIL-STD-1553 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Request a Quote Today for Pricing Info |
Associated part numbers for OmniBus MIL-STD-1553:
Ballard Technology OmniBus MIL-STD-1553 Frequently Asked Questions
Question: Why do the OmniBus products have so many part numbers?
Answer: The OmniBus product part numbers are the result of the board part number and the module part number. For example, part number 121-540 is an OmniBus cPCI (3U) with a single Level C channel MIL-STD-1553 module.
Question: What does the Level C functionality mean for channels on the module?
Answer: Level C functionality for channels on the MIL-STD-1553 module refers to the following features: 32 simultaneous terminals, protocol error injection, and monitoring features, such as concurrent terminal monitoring, filtering for subaddress, and filtering for terminal address.
Question: Which type of connector does the OmniBus MIL-STD-1553 module have?
Answer: The module has a 60-pin Molex® LFH™ connector.
