Keithley KPCI-PIO24 Plug-in Parallel Digital I/O Board
The KPCI-PIO24 is a 24-Channel parallel computerized interface board intended for the PCI bus. The Keithley KPCI-PIO 24 works with Windows 95/98/NT and utilizes the 32-bit width and the Plug and Play feature of the PCI bus. The KPCI-PIO24 additionally has an effectively available intrude on design. The KPCI-PIO24 meets a wide assortment of parallel I/O necessities, incorporating communicating with peripherals, working relays, and reading switch inputs. All I/O lines on the board are TTL compatible.
Most existing application programming and information procurement bundles work with the Keithley KPCI-PIO24 board. If the user wishes to reuse existing port I/O programs recently intended for ISA sheets, they can reference the Hardware I/O Emulation driver on the DriverLINX CDROM.
TestPoint is a completely included, coordinated application bundle that fuses numerous ordinarily utilized math, examination, report generation, and design capacities. TestPoint's graphical drag-and drop interface can be utilized to make information obtaining applications with insignificant programming for IEEE-488 instruments, information securing sheets, and RS232-485 instruments. TestPoint incorporates highlights for controlling outer gadgets, reacting to occasions, preparing information, making report records, and trading data with different Windows programs. This application also gives libraries for controlling most prevalent GPIB instruments. ActiveX controls plug specifically into TestPoint, permitting extra highlights from outside providers.
LabVIEW is a completely included graphical programming dialect used for virtual instrumentation. LabVIEW is comprised of an intuitive UI, complete with handles, slides, switches, diagrams, strip outlines, and other instrument board controls. The information driven software utilizes working obstructions that are practically wired together and pass information to one another.
| Model | KPCI-PIO24 |
|---|---|
| Manufacturer | Keithley |
| Type | Digital I/O Board |
| Digital I/O Lines | 24 |
| Resolution | 32-bit |
| Operating Temperature Range | 0 to 50 degrees Celsius |
| Power Requirements | +5V 400 mA |
| Dimensions | 5 × 4.25 × 0.75 in. (half slot) |
| Weight | 4 oz. |
| KPCI-PIO24 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for KPCI-PIO24:
Keithley KPCI-PIO24 Frequently Asked Questions
Question: Which type of connector does the Keithley KPCI-PIO 24 have?
Answer: The Keithley KPCI-PIO 24 has a 37-pin D-type male connector.
Question: Which externally accessible connections are possible with the KPCI-PIO24?
Answer: The KPCI-PIO24 has externally accessible connections of +5V, +12V, -12V, and -5V.
Question: How are the digital I/O lines on the Keithley KPCI-PIO24 grouped?
Answer: The digital I/O lines on the Keithley KPCI-PIO24 are grouped into three individual 8-bit ports referred to as PA, PB, and PC.
