Agilent U1069A Acqiris High Speed PCI Digitizer
The U1069A Acqiris High-Speed PCI Digitizer is manufactured by Agilent/HP/Keysight. The Agilent U1069A has an ADC (analog to digital converter) chipset. The U1069A is specially designed to achieve high performance ADC. The core design purpose is achieving optimum performance. The U1069A Acqiris High Speed PCI Digitizer comes with analog front-end technology that offers signal amplification, conditioning, and function crucial for attaining data acquisitions at high speeds (high GS/s rates).
The Agilent U1069A Acqiris High Speed PCI Digitizer has special components for dealing with digital data. The Agilent U1069A PCI Digitizer has 0.5 to 2 GS/s sampling rate, 500 MHz or 1 GHz bandwidth, and 1 or 2 channels. The Agilent U1069A comes with a large acquisition memory up to 16 Mpoints per channel. The U1069A has clear benefits of low power usage.
The U1069A Acqiris High Speed PCI Digitizer provides highly accurate measurements with low noise and harmonic levels. This accuracy is made possible with the help of complex circuits, ICs, and special techniques adopted for packaging. The Agilent U1069A offers an exclusive cooling system for use in harsh environments. This cooling scheme permits flexibility in operating temperature and ensures safe operation of all complex components of the module. Components’ life expectancy increases by this feature and helps minimize faults arising due to temperature. The Agilent U1069A Acqiris High Speed PCI Digitizer has applications in research, astronomy, aerospace, and physics.
Model | U1069A |
---|---|
Manufacturer | Keysight Agilent HP |
Series | High-Speed Digitizers |
Type | High-Speed PCI Digitizers |
Channels | 1 or 2 |
Bandwidth | 500 MHz or 1 GHz |
Acquisition Memory | 128-256 kpoints to 8-16 Mpoints, 128-256 kpoints to 2-4 Mpoints, or 256 kpoints to 16 Mpoints |
Sampling Rate | 2 GS/s |
Connectors | BNC or SMA, gold plated |
Coupling | AC and DC |
Power Consumption | <22 W without memory option; <25 W with memory option |
Dimensions | PCI long-length standard |
Warranty | 2-3 Year Warranty |
U1069A Manual | User Manual and Maintenance Manual Available for Download |
Pricing | Contact a Sales Representative for a quote. |
