E2925B
Modular Systems > Keysight Agilent HP > Protocol Analyzers and Exercisers
Description: | E2925B, 33 MHz, PCI Exerciser and Analyzer |
Need an Official Quote?
Or speak to a sales representative for additional information:
Agilent E2925B PCI Exerciser and Analyzer
The E2925B PCI Exerciser and Analyzer is manufactured by Agilent/HP/Keysight. The Agilent E2925B PCI Exerciser and Analyzer is an easy answer to PCI system performance measurement and verification, PCI system being used in the semiconductor and computer field. The Agilent E2925B comes with a real-time protocol checker, bus performance, and timing checker. The timing checker comes with the resolution of 250 ps. The PCI Exerciser and Analyzer contains both 32 bit and 64-bit signals and PCI commands. If there is a violation, the protocol checker is able to add all rules that are being violated and can list the number of errors found. The PCI protocol checker is also able to trigger the trace memory of the state analyzer.
The E2925B is a 33 MHz PCI Analyzer that allows all PCI signals. The Agilent E2925B has a 64-level trigger sequencer and 24 pattern terms. The Agilent E2925B PCI Exerciser and Analyzer can be externally controlled through either a 4 MB or a RS 232 interface (fast parallel). The Agilent E2925B comes with 155 x4M trace memory.
The E2925B has an on-board exerciser that is equipped with a completely manageable PCI master and target. The Agilent E2925B has 512 KB onboard data memory. The GUI (graphical user interface) supports the simple operation and fast performance of the E2925B PCI Exerciser and Analyzer. The Agilent E2925B PCI Exerciser and Analyzer can be used in applications, such as hardware design and software development.
Model | E2925B |
---|---|
Manufacturer | Keysight Agilent HP |
Series | Protocol Analyzers and Exercisers |
Type | PCI Exerciser and Analyzer |
PCI Exerciser | 33 MHz |
Pattern Terms | 24 |
Trigger Sequencer | 64-level |
On-board Data Memory | 512 KB |
Trace Memory | 155 x4M |
Warranty | 2-3 Year Warranty |
E2925B Manual | User Manual and Maintenance Manual Available for Download |
Pricing | Contact a Sales Representative for a quote. |
