Keysight N5306A Protocol Analyzer for PCIe 1.0 and 2.0
The N5306A is a Protocol Analyzer. Agilent/HP/Keysight Technologies is the manufacturer and developer of the N5306A. The N5306A Protocol Analyzer is used as an important component of the E2960 instruments. The Keysight N5306A is a part of the Protocol Analyzers and Exercisers designed by Agilent/HP/Keysight Technologies. The N5306A is controlled by software applications like Windows XP or Windows 7 operating systems on computers. The status of “obsolete” has been announced for the N5306A by the manufacturer.
The Keysight N5306A Protocol Analyzer can be fixed into the N5540A/N5541A N2X Chassis as an I/O module. The N5306A is offered with 2 GB of memory. The Keysight N5306A comes with 4-character LEDs for displaying status information. The N5306A Protocol Analyzer can be controlled through USB 2.0 or LAN. The N5306A supports 5 Gb/s PCIe cards. The Keysight N5306A functions with advanced triggering capabilities. The N5306A Protocol Analyzer is built with two timers/counters. The N5306A is featured with capturing of non-intrusive traffic.
The N5306A Protocol Analyzer is featured with traffic capturing the support of x1, x2, x4, x8, and x16 PCIe links. The Keysight N5306A works with a data rate of 2.5 and 5 GT/s. The N5306A has a data rate supported with ± 300 ppm. The N5306A Protocol Analyzer is available with the analyzer probe connector. The connector in the Keysight N5306A has REF clock-out and 10 MHz clock-out. The Keysight N5306A Protocol Analyzer works in the 0 to +55 °C operating temperature.
| Model | N5306A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Series | Protocol Analyzers and Exercisers |
| Type | Protocol Analyzer for PCIe 1.0 and 2.0 |
| Rates | 2.5 Gb/s and 5 GB/s |
| Memory | 2 GB |
| Display | 4-character LEDs display on the I/O module for status information |
| PCIe Links Supported | x1 through x8 PCIe links |
| Compatible Chassis | N5540A or N5541A |
| N5306A Manual | User Manual and Maintenance Manual Available for Download |
| Pricing | Contact a Sales Representative for a quote. |
