Keysight U4301B PCI Express Protocol Analyzer
The U4301B is a PCI Express Protocol Analyzer. The U4301B is developed by Agilent/HP/Keysight Technologies. The U4301B works with a host PC controller like the M9536A as recommended by Agilent/HP/Keysight Technologies. The Keysight U4301B can perform on a computer with a processor speed of 1 GHz, running on Windows 7/Windows 8 operating systems. The U4301B PCI Express Protocol Analyzer can be linked with a PC that has a minimum available memory of 2 GB.
The Keysight U4301B PCI Express Protocol Analyzer functions with a host PC that has 1.5 GB of disk space. The host PC of the U4301B is compatible with a PCIe x4 first-generation interface module. The Keysight U4301B has filters and triggers with a simple usage facility. The U4301B is a type of blade that can install in AXIe modules of the two-slot M9502A and the five-slot M9505A. The Keysight U4301B can decode the PCI Express data and display it in the packet viewer window. The U4301B PCI Express Protocol Analyzer can analyze traffic with a detailed traffic pattern.
The U4301B PCI Express Protocol Analyzer is featured with all kinds of supporting applications such as 2.5 GT/s first generation, 5.0 GT/s second generation, and 8 GT/s third generation PCIe with the x1 to x16 links. The Keysight U4301B PCI Express Protocol Analyzer can trigger at an input of 50 Ω, 3.3V Vmax, 2.0 V trigger output, and 20 ns of trigger duration. The Keysight U4301B can be operated at a maximum temperature of 40 °C. To analyze the traffic of the U.2 dual-link simultaneously, two U4301B PCI Express Protocol Analyzers are required.
Model | U4301B |
---|---|
Manufacturer | Keysight Agilent HP |
Series | Protocol Analyzers and Exercisers |
Type | PCI Express Protocol Analyzer |
Minimum Trigger Duration | 20 ns |
Maximum Operating Temperature | 40 degrees C |
Available Hard Disc Space | 1.5 GB |
Module Compatibility | PCIe Gen1 x4 interface module |
Speeds Supported | .5 GT/s (Gen1), 5.0 GT/s (Gen2), and 8.0 GT/s (Gen3) speeds |
Warranty | 2-3 Year Warranty |
U4301B Manual | User Manual and Maintenance Manual Available for Download |
Pricing | Contact a Sales Representative for a quote. |
