M9240A
Modular Systems > Keysight Agilent HP > PXI Accessories
Description: | M9240A, for use with M924XA Oscilloscopes, PXIe AutoProbe Power Module |
Need an Official Quote?
Or speak to a sales representative for additional information:
Keysight M9240A PXIe Auto-Probe Power Module
The M9240A is a PXIe Auto-Probe Power Module. The M9240A module is a product of Agilent/HP/Keysight Technologies. The M9240A module has been designed for use with modular oscilloscopes. The M9240A is equipped with multiple instruments like a 3-digit digital voltmeter, protocol analyzer, and arbitrary waveform generator of 20 MHz sine waves. The M9240A module can be used for a maximum of 1 GHz bandwidth with a 5 GSa/s rate. The M9240A comes with the 8-bit digital counter. Windows operating systems are used for the M9240A.
The Keysight M9240A PXIe Auto-Probe Power Module offers spectrum analysis with FFT measurements. The M9240A is used for Keysight active probes. The Keysight M9240A is designed to offer a connection interface for a maximum of 4 Keysight probes. The M9240A consumes a typical power of 35 Watts on the PXI connector for the Keysight active probes of the M924X Series. The M9240A module is built with a 3U slot. The M924XA Series modules are assembled with a net weight of 84 lbs.
The M9240A PXIe Auto-Probe Power Module functions with a minimum of 1 GB onboard memory. The calibration interval for the M924XA modules is one year. The Keysight M9240A has a probe impedance of 50 Ω/1 M Ω. The M9240A supports AC/DC input coupling. The M9240A module works with 1 GHz processor speed for the M924XA modules. The M9240A module is equipped with the associated M924XA 2.5 GB of disk space.
Model | M9240A |
---|---|
Manufacturer | Keysight Agilent HP |
Series | PXI Accessories |
Type | PXIe AutoProbe Power Module |
Compatible Models | M9241A, M9242A, or M9243A Modular Oscilloscopes |
Supplies Power for | Up to 4 probes |
Works with | Up to 2 modular oscilloscopes |
Warranty | 2-3 Year Warranty |
M9240A Manual | User Manual and Maintenance Manual Available for Download |
Pricing | Contact a Sales Representative for a quote. |
