M9302A
Modular Systems > Keysight Agilent HP > PXI
| Description: | Keysight M9032A, 2-slot, 3U, PXI Local Oscillator |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
Keysight M9302A PXI Local Oscillator
The Keysight M9302A Local Oscillator is enhanced for quick settling time to enable for quick frequency down conversion in several types of aerospace and defense applications. These applications include wireless communications and radar and wideband signal capture. The M9302A PXI Local Oscillator can function in a solitary radio organization or coordinating various configurations into a solitary gadget, simple access to the right test signals speeds approval and guarantees interoperability. The user can improve their work with Keysight Signal Studio programming, an adaptable arrangement of signal analysis devices that lessen the time the user spends reenacting signals. Its advanced execution reference signals, approved by Keysight, improve the portrayal and confirmation of gadgets.
The user can tweak the inherent signals with an adaptable signal generation, added substance insufficiencies, illustrations, helpful network and robotization, and coordinated and online documentation. The quick switching time and minimal phase noise ensure this PXI Local Oscillator is well-suited for working with microwave vector signal analyzers.
Programming examples can be found for this model in VisualStudio (VB.NET, C #, C/C ++), VEE, LabVIEW, LabWindows/CVI, and MATLAB. These examples can be easily and effectively adjusted to rapidly coordinate the module into the user’s test system. The Keysight M9302A Oscillator has a frequency range of 3 GHz to 10 GHz and has a tuning resolution of 0.1 Hz, with 1 ms of settling time. The tuning resolution offers a higher frequency preciseness. The user can also utilize a PXIe Hybrid, PXI-1, or cPCI(J1) slot for this PXI compliant Oscillator.
| Model | M9302A |
|---|---|
| Manufacturer | Keysight Agilent HP |
| Type | PXI Local Oscillator |
| Frequency Range | 3 GHz to 10 GHz |
| Slot Requirements | 2 |
| Tuning Resolution | 0.1 Hz |
| Power | +16 dBm ± 2 dB |
| Size | 3U |
| Weight | 2 lb. |
| Warranty | 2-3 Year Warranty |
| M9302A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Keysight M9302A Frequently Asked Questions
Question: Which products are required for the Keysight M9302A?
Answer: The Keysight M9302A requires a minimum of one PXI chassis and one PXI controller.
Question: Can the M9302A be calibrated?
Answer: Yes, the M9302A can be calibrated and is recommended for calibration once per year.
Question: What is the frequency temperature stability of the M9302A Oscillator?
Answer: The frequency temperature stability of the M9302A Oscillator is ± 0.5 ppm (over 0oC to 50oC).
