DAQCard-516

4.5/5 | 11 ratings

Modular Systems > National Instruments > DAQCards

Part Number DAQCard-516
Manufacturer/Brand National Instruments
Description: DAQCard-516, 16 bits, 8 Channel, Multifunction I/O Device
Request for Availablility
Fast Quote
Quoted Price
Same Day Calibration Available
2-3 Year Warranty Included
Free Ground Shipping
  Get Pricing

Need an Official Quote?



Or speak to a sales representative for additional information:


National Instruments DAQCard-516 Multifunction I/O Device

The DAQCard-516 is a Multifunction I/O Device developed by National Instruments. The NI DAQCard-516 is prepared with individual part numbers based on the nature of the operating used for the DAQCard-516 module. The DAQCard-516 is a part of the 516 product family series. The DAQCard-516 is operated with the NI-DAQ driver on Windows 2000/NT/9x and Mac operating systems. Using NI-DAQ allows users to swiftly and easily begin their application because it doesn’t require you to program the device on the register level. The DAQCard-516 is installed using application software like LabVIEW, BridgeVIEW, Measure, VirtualBench, Lookout, and Component-Works.

The NI DAQCard-516 is an affordable device designed for lab work in academic and industrial settings. Two optional accessories you can use with this device are the CB-27 I/O connector block and the PR27-30F I/O connector with 0.5 or 1 m connector cable. The DAQCard-516 renders multiple functions for input/output connections. The intention to produce a DAQCard-516 is to reach the level of 50 kS/s sampling rate. The DAQCard-516 is designed with 8 single-ended or 4 differential analog input channels. The resolution of 16-bits is incorporated for the DAQCard-516. This device has two 10 MHz timers/counters having 16-bit resolution for recording time sequences of the operations.

The DAQCard-516 is built with 8 digital input/output lines. The NI DAQCard-516 has a slave bus interface. The DAQCard-516 has a power requirement of 60 mA in operational mode or 20 mA in power-down mode at +5 VDC. This Multifunction I/O Device is equipped with a 27-pin male I/O connector.

ModelDAQCard-516
ManufacturerNational Instruments
FamilyNI-516
TypeMultifunction I/O Device
Analog Input Channels8 single-ended or 4 differential
Analog Input Resolution16 bits
Maximum Sampling Rate50 kS/s
Input CouplingDC
Digital I/O Channels4 input and 4 output
Timing I/O Channels3 counter/timers (1 dedicated to
analog input)
Bus Interface TypeSlave
I/O Connector27-pin male
PC Card TypeType II
Warranty2-3 Year Warranty
DAQCard-516 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the DAQCard-516:

777228-01, 777228-02, 777228-03, 18320.7, 183207-01, 183207C-01, 183207D-01, 183207F-01, 183210-01, 183210C-01
