PCI-4552
Modular Systems > National Instruments > DSA Devices
| Description: | PCI-4552, 4 Analog Input, Dynamic Signal Acquisition Board |
Item added to cart ✔ Keep Shopping
(1) PCI-4552 | PCI-4552, 4 Analog Input, Dynamic Signal Acquisition Board
What is Surplus New?
New Surplus: New Surplus condition is a New Condition, Surplus Stock unit with standard accessories and documentation. The product may ship in the manufacturer’s or Apex Waves’ packaging. New Surplus units include a 3 year warranty.
What is Refurbished?
Refurbished - Lightly Used, Fully Tested Using NI Software, Includes Manual & NI Certificates (if available) Cleaned & Re-Packaged in Static Bag, Box & Label Similar to Manufacturer - Includes 2 Year Warranty by Apex Waves
Please fill out the form below to send in your quote request and a representative will contact you with a formal quote.
Prefer to send a text message?
Text your name and parts to quote to: 1-919-809-5227
Please fill out the form below to send in your quote request and a representative will contact you with a formal quote.
Need an Official Quote?
Or speak to a sales representative for pricing & lead time:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments PCI-4552 Dynamic Signal Acquisition Device
The NI PCI-4552 device has 4 Analog Inputs, 16 bits input resolution, 204.8 kS/s sampling rate, ±10 mV to ±42.4 V input range, differential/single ended input configuration, 8 Digital I/O, and analog/digital triggering. The PCI 4552 Dynamic Signal Acquisition by NI is a highly performing, extremely precise analog I/O instrument designed for the PCI bus. This model can perform DIO functions, external trigger functions, and counter/timer functions.
The National Instruments PCI-4552 device utilizes differential (DIFF) inputs. The user can configure the input as a referenced single-ended (SE) channel with the use of the BNC-2140 DSA accessory. While the PCI-4552 is in the DIFF mode, a single line links to the positive input of the channel, while the other links to the negative input of the channel. The user can link the differential input to SE or DIFF signals, with options for ground-referenced or floating. Although, it is important to note that grounding the negative input from floating sources can enhance the measurement quality by eradicating the common-mode noise.
On the NI PCI-4552 Dynamic Signal Acquisition Device, the user can configure the trigger circuit to monitor one of the analog input channels to produce the level trigger. However, selecting an input channel as the level trigger channel does not influence the capabilities of the input channel.
The trigger-level range is the same as the analog input voltage range. In addition, the trigger-level resolution is identical to the accuracy for a selected input range on the PCI-4552.
The PCI-4552 is run using the NIDAQmx driver software which can be programmed using software packages or application development environments (ADEs) such as LabVIEW, LabWindows/CVI, Microsoft Visual C++, or Borland C++. The device software can be configured using the Measurement & Automation Explorer (MAX) tool. The NI device measures 4.19 x 12.28 x 0.73 in. in physical dimensions. It has a recommended operating temperature range of 0 °C to +40 °C, a storage temperature range of −25 °C to +85 °C, and a non-condensing relative humidity range of 10% to 95%.
PCI-4552 Obsolete Status has been announced by National Instruments, but will still be available for purchase and repairs by Apex Waves.
| Model | PCI-4552 |
|---|---|
| Manufacturer | National Instruments |
| Type | Dynamic Signal Acquisition Device |
| Analog Inputs | 4 |
| Input Resolution | 16 bits |
| Sampling Rate | 204.8 kS/s |
| Input Configuration | Differential/Single-ended |
| Digital I/O | 8 |
| Dimensions | 4.19 x 12.28 x 0.73 in. |
| Warranty | Three Year Warranty |
| PCI-4552 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
National Instruments PCI-4552 Frequently Asked Questions
Question: Can the PCI-4552 be used with NI-DAQmx?
Answer: No, the PCI-4552 can only be used with NI-DAQ.
Question: How often should the NI PCI-4552 be calibrated?
Answer: The NI PCI-4552 should be calibrated every year, unless it is being used for a demanding application. In that case, calibration can be completed every 90 days or six months.
Question: Which types of software can be used with the PCI 4552 device?
Answer: The PCI 4552 device can be used with ComponentWorks Measure, LabVIEW for Windows, VirtualBench-DSA, LabWindows/CVI for Windows, and NI-DAQ for PC Compatibles.
PCI-4552 PDF Manuals
ARCHIVED LABVIEW FUNCTION AND VI REFERENCE MANUAL.PDF
ARCHIVED NI 445X 455X CALIBRATION PROCEDURE.PDF
ARCHIVED TRADITIONAL NI DAQ USER MANUAL.PDF
DAQ GETTING STARTED GUIDE FOR PCI PCI EXPRESS.PDF
DAQ GETTING STARTED READ ME FIRST NI DAQMX AND DAQ DEVICE INSTALLATION GUIDE.PDF
GUIDE D_INITIATION DAQ POUR PCI PCI EXPRESS.PDF
C3A0 LIRE EN PREMIER GUIDE DE28099INSTALLATION DE NI DAQMX ET DES PC3A9RIPHC3A9RIQUES DAQ.PDF
