National Instruments PXIe-5745 PXI FlexRIO Signal Generator
The PXIe-5745 (Part Numbers: 785596-01, 785597-01, 785598-01, 785596-02, 785597-02, 785598-02) is a PXI FlexRIO Signal Generator. National Instruments is the manufacturer of the NI PXIe-5745. The PXIe-5745 is manufactured as a part of the FlexRIO Series by National Instruments. Since this PXI FlexRIO Signal Generator features six part numbers with varying specifications, there are three types of FPGAs available for the NI PXIe-5745. These FPGAs include a Kintex UltraScale KU035, a Kintex UltraScale JU040, and a Kintex UltraScale KU060 FPGA. The FPGA can be programmed with LabVIEW software.
The NI PXIe-5745 PXI FlexRIO Signal Generator can be used with the Flex-RIO driver software to initialize predefined waveforms. The National Instruments PXIe-5745 PXI FlexRIO Signal Generator delivers direct radio frequency (RF) signal generation, alongside 12-bits analog input resolution. The NI PXIe-5745 is made with two channels. The PXIe-5745 offers a maximum sampling rate of 6.4 GS/s.
The NI PXIe-5745 PXI FlexRIO Signal Generator is prepared with a dynamic RAM of 0 or 4 GB, based on the part number. The DRAM clock rate of the PXIe-5745 is 1064 MHz. The NI PXIe-5745 is recommended as an ideal module for high-channel signal generation. The PXIe-5745 is the most suitable PXI FlexRIO Signal Generator for electronic warfare, radar, and signal communications. The NI PXIe-5745 has an output impedance of 50 Ω and works with AC output coupling. The PXIe-5745 is equipped with a DAC38RF82 DAC. The PXIe-5745 FlexRIO Signal Generator works with total power of 58 W.
| Model | PXIe-5745 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 785596-01, 785597-01, 785598-01, 785596-02, 785597-02, 785598-02 |
| Type | PXI FlexRIO Signal Generator |
| Dynamic RAM | 0 to 4 GB |
| FPGA Type | Kintex UltraScale KU035, Kintex UltraScale KU040, or Kintex UltraScale KU060 |
| Channels | 2 |
| Maximum Total Power | 58 W |
| Dimensions | 8.5 in. × 0.8 in. × 5.1 in. |
| Weight | 17.3 oz. |
| PXIe-5745 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for PXIe-5745:
National Instruments PXIe-5745 Frequently Asked Questions
Question: What is the difference between the four part numbers of the PXIe-5745?
Answer: The part numbers for the PXIe-5745 differ in their FPGAs- KU035 (785596-01, 785596-02), KU040 (785597-01, 785597-02), and KU060 (785598-01, 785598-02). Part numbers 785596-02, 785597-02, and 785598-02 also include an analog output filter.
Question: What is the signal type of the PXIe-5745?
Answer: The PXIe-5745 has a single-ended signal type.
Question: What is the PXIe-5745 memory size?
Answer: The PXIe-5745 has 4 GB of memory, divided into 2 banks of 2 GB each.
| Part Number | FPGA | Additional Attributes |
| 785596-01 | KU035 | |
| 785597-01 | KU040 | |
| 785598-01 | KU060 | |
| 785596-02 | KU035 | Analog Output Filter |
| 785597-02 | KU040 | Analog Output Filter |
| 785598-02 | KU060 | Analog Output Filter |
