National Instruments 780935-01 PCIe-GPIB Instrument Control Interface
The National Instruments 780935-01 (PCIe-GPIB) is a high-performance IEEE 488 controller card designed to connect host computers to GPIB-enabled instruments via a x1 PCI Express slot. Featuring a standard 24-pin female IEEE 488 connector on the rear panel, the device manages 24 total signal terminals—including 8 data bits and dedicated handshaking lines (DAV, NRFD, and NDAC) for precise hardware-coordinated data transfer. It supports standard 3-wire GPIB transfer rates up to 1,670 kB/s as well as high-speed HS488 transfers up to 7,980 kB/s, offering seamless compatibility with both legacy test equipment and modern high-throughput setups.
Engineered with noise immunity in mind, the card pairs critical handshake and control lines (DAV, NRFD, NDAC, IFC, SRQ, and ATN) with dedicated twisted ground wires to minimize crosstalk over long cable runs, while terminal 24 serves as a unified logic ground reference. Operating on a 3.3 V DC supply (360 mA nominal, 560 mA peak), its compact board footprint (9.754 cm x 6.888 cm) ensures effortless installation into low-profile or space-constrained computer chassis.
The 780935-01 operates across an ambient temperature range of 0°C to 55°C (10% to 90% RH non-condensing) and withstands storage temperatures from -20°C to 70°C. Included with the hardware is dedicated GPIB analyzer software, enabling real-time bus traffic monitoring and command debugging. Combined with NI-488.2 driver support, this card delivers a robust, reliable foundation for automated test equipment (ATE) systems, laboratory automation, and complex data acquisition environments.
Part Number |
780935-01 |
|---|---|
Model Name |
PCIe-GPIB |
Part Type |
PCI Express, Analyzer Software Included, IEEE 488 GPIB Instrument Control Device |
Dimensions |
9.754 cm × 6.888 cm |
GPIB Connector |
IEEE 488 24-pin connector |
PCI Express Connector |
x1 |
Operating ambient temperature |
0 °C to 55 °C |
Storage ambient temperature |
-20 °C to 70 °C |
Total Terminals |
24 |
Storage relative humidity |
5% to 95%, noncondensing |
