National Instruments GP36/2-DIN160 Spring Pin Cable
The GP36/2-DIN160 (part numbers: 144756-32, 144756-40) from National Instruments is a versatile spring pin cable. One end is equipped with two 36-position pogo pin connectors, for a total of 72 pins. The other end features a 160-Pin DIN Connector. The difference between the two part numbers of the GP36/2-DIN160 is the length. Part number 144756-32 measures 32 inches, while part number 144756-40 has a length of 40 inches.
The standout feature of this cable are the dual pogo pin connectors. These small connector pins are spring-loaded, a type that is well known for their use in creating strong electrical connections within electronic systems. The term "pogo pin" was inspired by the design of the connector, which is reminiscent of a classic pogo stick with an internal spring that is able to compress and sustain steady contact pressure. The "GP" of the cable name stands for "General Purpose".
A typical DIN connector on a cable is used on the end that connects to the instrument or system. The DIN connector of the GP36/2-DIN160 is 160-pins, making it a high-density and multi-row connector perfect for a wide range of test and measurement applications.
| Model | GP36-2-DIN160 |
|---|---|
| Part Numbers | 144756-32, 144756-40 |
| Part Type | NI Cable |
| Manufacturer | National Instruments |
| Connector A | Dual 36-Position Pogo Pin |
| Connector B | 160-Pin DIN Connector |
| Length(s) | 32 in and 40 in |
| Pin Type | Spring Loaded |
| Price | Request a Quote for Pricing Information |
Associated part numbers for GP36-2-DIN160:
