PS-3
Modular Systems > National Instruments > NI Power Supplies
| Description: | PS-3, 55 W, 13.8 VDC, Power Supply |
(expedited shipping options available)
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments PS-3 DC Power Supply
Featured with a universal IEC power input, the NI PS-3 (Part Numbers: 777585-01, 777585-02, 777585-03, 777585-04, 777585-05, and 777585-06) is a legacy DC Power Supply. This model is designed to provide 13.8 VDC and 55 watts of power at its output terminals. Since it is a universal Power Supply, the PS-3 can be operated over an input range of 90 to 264 VAC. For 12 volt DC batteries this Power Supply can also be used as a float charger. The National Instruments PS-3 is designed as a power brick since it comes with the internal gear packed in a case identical to an AC plug.
This Power Supply is specifically designed to fulfill Compact FieldPoint system power requirements. A single PS-3 can provide adequate power to energize one bank of FieldPoint I/O modules (or eight I/O modules). The installation of this model is simple because its output can be directly inserted into the power jack of the FieldPoint terminal. The National Instruments PS-3 is known for its safety performance, which is a function of its integrated safety mechanisms. Tripping and lockout mechanisms of the Power Supply block the path of faults with the potential to travel from load to source.
The NI PS-3 does not require any external cooling. The National Instruments PS-3 DC Power Supply cannot be operated in either parallel or series arrangement with other supplies. Although it is a Power Supply from the National Instruments, the user can utilize it with other devices where similar ratings are required.
| Model | PS-3 |
|---|---|
| Manufacturer | National Instruments |
| Part Numbers | 777585-01, 777585-02, 777585-03, 777585-04, 777585-05, 777585-06 |
| Type | DC Power Supply |
| Output Voltage | 13.8 VDC |
| Output Current | 4 A |
| Input Voltage | 100, 120, 230, or 240 VAC |
| Warranty | 2-3 Year Warranty |
| PS-3 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the PS-3:
777585-01, 777585-02, 777585-03, 777585-04, 777585-05, 777585-06
National Instruments PS-3 Frequently Asked Questions
Question: How many Compact FieldPoint I/O modules can the PS-3 power?
Answer: The PS-3 can power as many as eight Compact FieldPoint I/O modules or an entire bank.
Question: Which devices can the NI PS-3 charge?
Answer: The NI PS-3 can function as a float charger for 12 VDC batteries.
Question: What is the output voltage for the PS-3?
Answer: The output voltage for the PS-3 is 13.8 VDC.
