HPE Edgeline EL4000, 4-Slot, Converged IoT PXI Chassis
Need an Official Quote?
HPE/National Instruments Edgeline EL4000 Converged IoT PXI Chassis
Featured with 8 GB/s bandwidth and tremendous computing power, the HPE Edgeline EL4000 (Part Number: 785690-01) is a Converged IoT PXI Chassis. This system is designed to provide large storage capacity, device management, remote maintenance, enterprise-level security, and various other features. The HPE Edgeline EL4000 supports fast acquisition of IoT data from the layer at which it is being generated. The inclusion of this powerful industrial computing system can assist bring better performance and greater stability to your entire network regardless of the kind data being handled. In addition, the HPE Edgeline EL4000 can greatly improve the rates at which the data can be acquired, processed, and analyzed. This Converged IoT PXI Chassis is offered in a slim, 1U form factor.
You can load your National Instruments/HPE Edgeline EL4000 Converged IoT PXI Chassis with a combination of ProLiant m510 or ProLiant m710x computer nodes. A total of four computer nodes can be loaded in the HPE Edgeline EL4000 at a time. This converged system can be acquired in a variety of variations in terms of I/O and networking. As far as its network capabilities are concerned, the HPE Edgeline EL4000 Converged IoT PXI Chassis can operate with InfiniBand, 10 Gb Ethernet, Fiber Channel, or 40 Gb Ethernet. This PXI Chassis comes equipped with 1 iLO RJ45 management port as well. Thus, you can easily implement the state-of-the-art HPE Integrated Lights Out technology with this system in a similar fashion as it was provided for HPE ProLiant Servers.
Model | HPE Edgeline EL4000 |
---|---|
Manufacturer | Hewlett Packard Enterprise/National Instruments |
Part Number | 785690-01 |
Type | Converged IoT PXI Chassis |
PXI Module Mounting Location | Rear |
Server Cartridge Mounting Location | Sides |
Network | 2 port 10GbE pass through per cartridge (dual, combined QSFP+) or aggregated 2 port 10GbE SFP+ uplinks (layer 2 switch) |
Slots | 4 |
Dimensions | 1U, 23" deep, 17" wide, reversible rackmount with slide rails |
Weight | 847535-B21: 10 GbE 2 x SFP+ switch system - 38.85 lb. 847534-B21: 4 x 10 GbE 2xQSFP+ Pass Thru system - 37.92 lb. |
Power | 95–265 VAC or -48 VDC input, 1+1 redundant power, high efficiency |
Warranty | 2-3 Year Warranty |
HPE Edgeline EL4000 Manual | User Manual and Maintenance Manual Available for Download |
Price | Contact a sales representative for a quote. |
Associated part numbers for the HPE Edgeline EL4000:
751299-01, 785690-01, 785690-02
