National Instruments PXI-7954R PXI FPGA Module for FlexRIO

The NI PXI-7954R (Part Number: 780563-01) has 66 differential general purpose I/O pairs which can be configured as 132 single-ended signals. This FPGA Module for FlexRIO also has a Virtex-5 LX110 FPGA, two separate 64 MB banks of onboard DRAM, and a maximum of 400 Mb/s single-ended configuration rates. This module and other PXI FPGA Modules for FlexRIO are suited for systems that necessitate synchronization, high-performance information streaming, high channel density, and processing.

The National Instruments PXI-7954R FPGA Module for FlexRIO can be used with the following operating systems: Windows XP Pro x32 Service Pack 1 or 2, Windows 7, or Windows Vista. Other required components to operate the module include a compatible chassis and controller, a minimum of one cable to link signals to the FlexRIO device, LabVIEW, NI FlexRIO Adapter Module Support, the NI-RIO driver, and the LabVIEW FPGA Module. The LabVIEW Real-Time Module is optional. It is also important to note that the adapter module will not show up in MAX, only FPGA modules will appear in MAX.

A few of the features supported by the PXI-7954R module includes single-cycle Timed Loop, arbitration, and FPGA base clocks. There are many advantages to using FPGA technology in a test system, including the price, performance, dependability, long-lasting maintenance, and time to market.

The NI PXI-7954R FlexRIO FPGA Module must be utilized with a FlexRIO Adapter Module if the user is using their FlexRIO system for signal input/output. However, the PXI 7954R module can be utilized without a FlexRIO Adapter Module if it is being used for peer-to-peer streaming or coprocessing.

PXI-7954R Mature Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelPXI-7954R
Part Number780563-01
ManufacturerNational Instruments
SeriesR Series
TypePXI FPGA Module for FlexRIO
FPGAVirtex-5 LX110
GPIO66 differential or 132 single-ended
DRAM128 MB
Dimensions7.4 in. × 5.1 in.
Weight6.7 oz.
WarrantyOne Year Warranty
PXI-7954R ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments PXI-7954R Frequently Asked Questions



Question: How many DMA channels does the NI PXI-7954R?



Answer: The NI PXI-7954R has 3 DMA channels.



Question: What are the connection resources for the PXI-7954R?



Answer: The connection resources for the PXI-7954R are the PXI star trigger, PXI_CLK10, and PXI triggers.



Question: Which type of I/O connector does the NI PXI-7954R have?



Answer: The NI PXI-7954R has a high- density card edge I/O connector.



Question: What is the maximum working voltage for the PXI-7954R module?



Answer: The maximum working voltage for the PXI-7954R module is 0 V to 3.3 V, Measurement Category I.
