National Instruments SCXI-1600 Data Acquisition Module

Featured with a 16-bit ADC, the NI SCXI-1600 (Part Number: 776572-1600) is a USB Data Acquisition Module (DAQ) for SCXI. This module is a full-featured control and data module for SCXI digital I/O, switching, analog input, and analog output modules. The user can install the SCXI-1600 in a Signal Conditioning Extension for Instrumentation (SCXI) chassis and provide clock, calibration, and external digital trigger connections for all other modules installed in the chassis. With this module, the user can get any SCXI chassis transformed into a robust and reliable plug & play data acquisition system.

The NI SCXI 1600 receives analog signals from other modules and digitizes, amplifies, and transfers data via a USB port. It is one of the easiest to configure and calibrate devices since it has no jumpers, potentiometers, or DIP switches. By connecting it to other SCXI modules, this module can acquire up to 352 analog signals from RTDs, thermocouples, strain gauges, current sources, and voltages. The NI SCXI 1600 is USB compatible, which supports powered or hot insertion into the USB port. For time-related functions, this Data Acquisition Module utilizes a robust system timing controller called the National Instruments DAQ-STC.

To control the analog input, the DAQ-STC consists of three timing groups. This module comes equipped with four LEDs on the front panel. There is a set of green LEDs to monitor the V+ and V– rails of the chassis. The other two LEDs show the active and ready state of the SCXI-1600 Data Acquisition Module. For calibration, a dedicated BNC connector is also provided on the front panel of this module.

SCXI-1600 Obsolete Status has been announced by National Instruments, but the module will still be available for purchase and repairs by Apex Waves.

ModelSCXI-1600
ManufacturerNational Instruments
Part Number776572-1600
SeriesSCXI Series
TypeData Acquisition Module
Resolution16 bits
Sampling Rate200 kS/s
Dimensions7.2 by 6.8 by 1.2 in.
Calibration Interval1 year
WarrantyOne Year Warranty
SCXI-1600 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

National Instruments SCXI-1600 Frequently Asked Questions



Question: What is the power requirement for the SCXI 1600?



Answer: The power requirement for the SCXI 1600 is 115 mA maximum at +22 V supply and 135 mA maximum at -22 V supply.



Question: Which type of I/O connector does the SCXI-1600 have?



Answer: The SCXI-1600 has 3 BNC connectors and 1 USB front connector.



Question: What is the FIFO buffer size of the NI SCXI 1600?



Answer: The FIFO buffer size of the NI SCXI 1600 is 4,096 samples.



Question: What is the sampling rate for the NI SCXI-1600?



Answer: The NI SCXI-1600 has a sampling rate of 200 kS/s.
