National Instruments VXIpc-486 Model 566 Embedded Computer
The National Instruments VXIpc-486 Model 566 is an Embedded Computer. This controller comes equipped with a powerful microprocessor, integrated storage disk, and various other onboard resources. In fact, the NI VXIpc-486 Model 566 can be considered a robust, standalone computer. This device features a powerful regime of communication interfaces. Thus, it can be utilized in a variety of hardware configurations. the VXIpc-486 Model 500 Series devices are offered with super VGA capability. By using super VGA, you can increase the display resolution from 640 x 480 pixels to 1024 x 768 pixels.
The NI VXIpc-486 Model 566 supports multiple Slot 0 settings – a feature that enables these devices to get synchronized and operate in multiple-chassis arrangements. This Embedded Computer has a built-in diagnostics facility that performs several tests upon startup. The device is not allowed to start if any diagnostic test fails and users are informed via a dedicated FAILURE LED. In addition, various other indication LEDs are incorporated to provide the user with real-time information.
Since it is an Embedded Computer, the VXIpc-486 Model 566 can host numerous PC compatible expansion modules. This model comes equipped with an enhanced version of BIOS. The BIOS setup and system parameters are saved in a battery-backed CMOS RAM. Thus, all your settings remain unaffected when the device is removed from the chassis.
VXIpc-486 Model 566 Obsolete Status has been announced by National Instruments, but the embedded computer will still be available for purchase and repairs by Apex Waves.
| Model | VXIpc-486 Model 566 |
|---|---|
| Manufacturer | National Instruments |
| Series | Model 500 Series |
| Type | Embedded Computer |
| CPU | 66 MHz 80486DX2 |
| Slots | 1 or 2 |
| RAM | 4, 5, 8, 16, or 32 MB |
| Local Bus Keying | Class 1, TTL |
| Size | C-size |
| Operating Relative Humidity | 0% to 95% noncondensing |
| VXIpc-486 Model 566 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
