National Instruments VXIpc-650 Embedded Controller

The VXIpc-650 is an Embedded Controller that belongs to the VXI/VMEpc 600 Series. The VXIpc-650 Controller is designed by National Instruments. The NI VXIpc-650 is a B-size embedded computer, which is based on x86 Processor architecture and on the Peripheral Component Interface (PCI) bus. The VXIpc-650 can be installed in two B-size slots in a VXI mainframe. This high-performance, simple to utilize controller, offers complete VXI functionality via interactive utilities and C function calls.

The National Instruments VXIpc-650 Embedded Controller additionally has Ethernet capability, along with an IEEE 488.2 interface compatible with the NI-488.2 architecture. This embedded computer can take complete advantage of the VXI backplane capabilities, providing you control of VXI registers, trigger, memory, and interrupts. The VXIpc-650 can be utilized to reach complete VXI slot 0 control of a VXI system. The module can be installed in another slot and used in Non-Slot 0 mode as well. When switching between these two modes, it is not required to change any jumpers.

This Embedded Controller is VXI plug-and-play compliant and is compatible with PC-compatible software tools. Other compatible software includes NI-488.2 bus interface software, NI-VXI, NI LabVIEW, NI-VISA, and LabWindows/CVI application software. A few types of optional items that can be used with the NI VXIpc-650 are a 2 m single-shielded GPIB cable, a COM1/2 adapter cable, and an enhanced parallel port adapter cable.

VXIpc-650 Obsolete Status has been announced by National Instruments, but the controller will still be available for purchase and repairs by Apex Waves.

ModelVXIpc-650
ManufacturerNational Instruments
SeriesVXI/VMEpc 600 Series
TypeEmbedded Controller
Slot RequirementsTwo VXI/VME B-size slots
CompatibilityFully compatible with VXI Specification
SizeTwo-slot VXI/VMEbus B-size module
VXI Keying ClassClass 1 TTL
Dimensions9.18 x 6.3 x 0.06 in.
Weight2.5 lb.
Warranty2-3 Year Warranty
VXIpc-650 ManualUser Manual and Maintenance Manual Available for Download
PriceContact a sales representative for a quote.

Associated part numbers for the VXIpc-650:

183851B-01, 183851C-01, 183851D-01, 185194A-320, 185194B-220, 777723A-02, 777723A-04
