RADX Technologies PXIe-GPU-T400-4GB Catalyst PXIe-GPU Module
A commercial off-the-shelf (COTS) PXIe-GPU module, the PXIe-GPU-T400-4GB from RADX Technologies is made for even the most demanding systems. It contains an inbuilt NVIDIA Turing T600 PCIe professional GPU with a 640 x CUDA core that allows for 4GB of memory. This module removes the need for separate external GPU servers by integrating the power of professional NVIDIA graphics inside a typical PXIe chassis. For difficult test and measurement applications, such as artificial intelligence (AI), video, signals, and pictures, this module excels. One G6 NVENC for video encoding and one G4 NVDEC for video decoding are included in the NVIDIA GPU.
The PXIe-GPU-T400-4GB has strong software support and works with Windows 10 and 11, desktop Linux 64-bit, and NI's RT Linux. By replacing end-of-life integrated GPUs in legacy embedded controllers, this module helps resolve a critical operating system (OS) issue by offering complete security compliance for Windows 11. Programming it in LabVIEW, Python, MATLAB, C, and C++ is incredibly simple for users.
With only one PXIe slot and 38 W of electricity per slot, this PXIe-GPU module is incredibly power-efficient. It provides four Mini DP 1.4a ports for the display and can function securely in nearly any recommended PXIe chassis. A PXIe module thermal solution comprising a RADX Passive Aluminum Heat Sink with an air flow of roughly 152 LFM is included with the PXIe-GPU-T400-2GB.
This PXIe-GPU module should be used in settings with noncondensing humidity levels between 10% and 90% and temperatures between 0 °C and 55 °C. It should be kept between -40 °C and 85 °C while not in use. The PXIe-GPU-T400-4GB weighs just 0.4 kg (0.7 lbs) and has physical dimensions of 100 mm x 160 mm x 20.32 mm (3.94 in x 6.30 in x 0.80 in).
Designed and assembled in the United States, this module is fully BAA/TAA compliant. It is available directly from Apex Waves, an authorized distributor!
| Model | PXIe-GPU-T600-4GB |
|---|---|
| Manufacturer | RADX |
| Part Type | RADX Catalyst & ORCA-C2X PXIeGPU |
| NVIDIA RTX GPU | Turing / Quadro T600 |
| GDDR6 / 7 | 4 GB, 160 GBPS |
| TFLOPS | 1.7 |
| CUDA RT-Tensor Cores | 640-0-0 |
| NVDEC | 1 x G4 |
| NVENC | 1 x G6 |
| Max W/Slot | 38 W |
| Distributor | Apex Waves |
