Tektronix DPO7054 Digital Phosphor Oscilloscope
The Tektronix DPO7054 Digital Phosphor Oscilloscope has 3.5 GHz Bandwidth for Serial and Digital applications, up to 40 GS/s Real-time Sample Rate on One Channel and up to 10 GS/s on All Four Channels, up to 400 Megasamples Record Length with MultiView Zoom™, more than 250000 wfms/s Maximum Waveform Capture Rate, user-selectable bandwidth limit filters for better low-frequency measurement accuracy, Myscope Custom Windows, right mouse click menus, and OpenChoice® Software with Microsoft Windows XP OS.
The Tektronix DPO7054 is part of the new era of real-time digital phosphor oscilloscopes and is the industry’s best answer for the challenging sign integrity issues faced by specialists while verifying, characterizing, debugging, and testing complex electronic designs. This instrument offers remarkable execution in signal acquisition and analysis, operational simplicity, and unmatched debugging instruments to accelerate normal assignments. This unit comes with the biggest screen in the business and the best intuitive user interface. Both features provide easy access to the maximum amount of information.
The high bandwidth up to 3.5 GHz is matched across 2, 3, or 4 channels and enabled by Tektronix proprietary DSP enhancement. The user-selectable DSP on every channel gives magnitude, phase correction, and development with 3.5 GHz for more exact signal fidelity for complex estimations. The DSP filter on every channel can additionally be switched off to take advantage of true 2.5 GHz analog bandwidth for applications needing the highest available raw data capture.
The manual for this model is available on the ApexWaves.com website if you would like further information.
| Model | DPO7054 |
|---|---|
| Manufacturer | Tektronix |
| Series | DPO7000 |
| Type | Digital Phosphor Oscilloscope |
| Channels | 4 |
| Bandwidth | 500 MHz |
| Rise Time | 460 ps |
| DPO7054 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
