Cisco PWR-IE170W-PC-AC= DIN-Rail Power Supply
The PWR-IE170W-PC-AC= manufactured by Cisco is a robust and reliable DIN-Rail Power supply. Specifically designed for rugged industrial applications, this power supply is an excellent choice for use with routers, ethernet switches, and more. The PWR-IE170W-PC-AC= offers full support for PoE and PoE+ (Power over Ethernet), equipping it for use with the high-capacity demands of modern industrial networks.
In terms of power, this versatile AC to DC power supply can either accept AC (alternating current) and convert it into DC (direct current) output, or it can accept a high-voltage DC input. The rated nominal input operating range of the device is 100-240 V at 2.3 A at 50-60Hz for AC and is 125-250 V at 2.1A for DC. The input voltage operating range that is supported by the PWR-IE170W-PC-AC= is 90-264 V for AC or 106-300 V for DC.
The nominal output range of the device is 54 VDC at 3.2A and it has a maximum output power of 170 W. The typical efficiency of the device is 88%. When at 100% load, the device has a holdup time or 20 ms. This power supply is well protected, with output protections safeguarding against overvoltage, overcurrent, overtemperature, and short circuiting.
The operating environment for the PWR-IE170W-PC-AC= should be kept within a temperature range of -40°C to 75°C with a relative humidity that is non-condensing and measures less than 95%. When not in use, the power supply can be safely kept in environmental storage temperatures ranging from -40°C to 85°C. This device does not include power derating, and it has an IP rating of IP20. The physical dimensions of the PWR-IE170W-PC-AC= measure 96 mm x 150 mm x 146 mm (3.77 in x 5.90 in x 5.74 in). It weighs in at 1.76 kg (3.88 lb).
| Model | PWR-IE170W-PC-AC |
|---|---|
| Part Type | DIN-Rail Power Supply |
| Manufacturer | Cisco |
| Supported Input Voltage | 90-264 V (AC), 106-300 V (DC) |
| Output Power | 170 W Maximum |
| PoE Support? | Yes |
| Operating Temp Range | -40°C to 75°C |
| Storage Temp Range | -40°C to 85°C |
| Dimensions | 96 mm x 150 mm x 146 mm (3.77 in x 5.90 in x 5.74 in) |
| Weight | 1.76 kg (3.88 lb) |
| Pricing | Request a Quote for more Information |
