SL Power/Condor GPC140-15 Switching Power Supply
The GPC 140-15 is a Switching Power Supply by SL Power/Condor. This model comes with an input voltage range from 85-264 Vac. It has a single phase frequency range from 47 to 63 Hz. The switch has a maximum input current at 120 Vac and delivers a complete output load of about 3.7 A with 60 Hz at this voltage. The Condor GPC 140-15 has a hold-up time of 20 ms. It reaches the full load from the loss of ac input in this time frame with the minor voltage of about 115 Vac.
The Condor GPC 140-15 has a convection output power of about 140 W. The output power increases airflow up to 160 W. The model can maintain the peak rating with the maximum duration of 60 seconds. The duty cycle is around 10% during this time. The Condor GPC 140-15 can provide output overload protection. It provides protection from short circuits. It restricts the cycling type power of short circuits on output 1. This model can recover automatically after a fault.
The Condor GPC 140-15 has a 70% efficiency rate at complete load with the minor input voltage. The switching efficiency depends on the distribution of the load. It also depends on the switch model. The model also provides overvoltage protection of Main outputs up to 130%. This Switching Power Supply is equipped with an internal ac fuse to provide input protection. The fuse blows if any disastrous failure happens in the unit. The GPC140-15 Switching Power Supply is also featured with a thermal shutdown function.
| Model | GPC140-15 |
|---|---|
| Manufacturer | SL Power/Condor |
| Type | Switching Power Supply |
| AC Input | 85-264 Vac, 47-63 Hz single phase |
| Output | 15 V |
| Output Minimum | 0 A |
| Output Maximum (B) | 9.3 A |
| Output Maximum (C) | 10.7 A |
| GPC140-15 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
