TDK Lambda GEN300-17 Programmable DC Power Supply
The TDK Lambda GEN300-17 is a programmable DC power supply for industrial automation applications. The rated output voltage for the model reaches 300 Vdc, adjustable from 0 to 300 Vdc. The rated output current reaches 17 A, adjustable from 0 to 17 A. The total rated output power for the power supply measures 5100 W under full load conditions.
The GEN300-17 supports parallel operation with active current sharing across up to four units. The independent remote on/off and remote enable/disable functions support flexible system integration. The external analog programming and monitoring operate through user-selectable 0 – 5 V or 0 – 10 V signals.
The nominal dimensions for the Programmable DC Power Supply are 423 mm wide by 88 mm high by 442.5 mm deep. The typical weight for the unit reaches approximately 16 kg. The operating temperature range for the power supply spans 0 to 50 degrees Celsius at full load. The storage temperature range spans negative 20 to 85 degrees Celsius.
The operating humidity for the GEN300-17 ranges from 20 to 90 percent RH non-condensing. The storage humidity ranges from 10 to 95 percent RH non-condensing. It meets vibration requirements under MIL-810F when fixed to a vibrating surface. The operating altitude for the GEN300-17 Programmable DC Power Supply reaches 10000 ft with derating of 2 percent per 100 m. The non-operating storage altitude for the model reaches up to 40000 ft. These specifications make this programmable DC power supply suitable for demanding industrial automation environments.
The GEN300-17 power supply operates from a 3-phase input source. The input voltage range for the model spans 170 to 265 Vac across all phases. The input frequency for the power supply spans 47 to 63 Hz. The typical conversion efficiency for the unit reaches 88% at rated output. The voltage ripple noise for the model stays below 0.06 Vrms across 5 Hz to 1 MHz. The high-resolution 16-bit ADCs and DACs give the model precise digital control. The reliable encoders allow smooth voltage and current adjustments from the front panel.
| Model | GEN300-17 |
|---|---|
| Manufacturer | TDK Lambda |
| Part Type | Programmable DC Power Supply |
| Output Current | 0 To 17 A |
| Input Frequency Range | 47 to 63 Hz |
| Rated Output Voltage DC | 300 Vdc |
| Input Voltage Range: AC | 170 To 265 Vac |
| Rated Output Current | 17 A |
| Input Type | 3-Phase |
| Output Voltage DC | 0 To 300Vdc |
Associated part numbers for GEN300-17:
