TDK Lambda HWS1500-12 Single Output Industrial Power Supply
The TDK Lambda HWS1500-12 is a single output industrial power supply with a 1500 W continuous output rating. This unit delivers a regulated 12 Vdc output and supports a maximum output current of 125 A. The model is specifically engineered to serve demanding industrial control and automation system applications reliably. Its wide range single phase AC input accommodates voltage levels spanning 85 to 265 Vac. The model requires no minimum load making it well suited for variable demand industrial environments. The overcurrent protection in the power supply engages beyond 105 % of rated output current to safeguard all connected downstream equipment effectively. The DC input support on the power supply extends from 120 to 330 Vdc. The output voltage is adjustable within the range of 9.6 to 14.4Vdc to suit varying system requirements.
The HWS1500-12 operates at a typical efficiency of 85 % effectively minimizing energy losses during sustained operation. A temperature coefficient of 0.02%/°C maintains consistent output voltage stability across the operating temperature range. The remote on/off function in this model is electrically isolated from the DC output enabling controlled and safe switching. A green LED indicator confirms the active and stable DC output status of the unit at a glance.
The physical dimensions of the Industrial Power Supply are 126.5 mm wide, 82 mm tall and 280 mm deep in nominal measurements. The unit has a nominal weight of 3800g reflecting robust build quality suited for permanent industrial panel installation. The remote sense capability on the model compensates for resistive voltage drops across output wiring. Up to five units can be operated in parallel using a straightforward single wire connection method. This parallel capability allows system designers to scale output current capacity without complex external control circuits. An integrated internal fan provides active cooling to sustain reliable thermal performance throughout all continuous load conditions.
The HWS1500-12 Power Supply operates within - 10 to + 70 °C with linear output derating to 50 % load from 50 °C. The storage temperature limits range from - 30 to + 85 °C ensuring safe handling in long term industrial warehousing conditions.
| Model | HWS1500-12 |
|---|---|
| Manufacturer | TDK Lambda |
| Part Type | Single Output Industrial Power Supply |
| Maximum Output Current | 125 A |
| Input Voltage Range[AC] | 85 to 265Vac |
| Output Voltage Range[DC] | 9.6 to 14.4Vdc |
| Efficiency | 85% Typ. |
| Input Voltage Range[DC] | 120 to 330Vdc |
| Rated Output Voltage[DC] | 12Vdc |
| Input | Single-phase |
