TDK Lambda Vega 650 Power Supply
Designed to deliver 650W maximum output power at nominal output voltages, the TDK Lambda Vega 650 is a multiple output modular power supply. This model comes with an extensive range output voltage adjustment via remote adjustment pin or potentiometer. The TDK Lambda Vega 650 offers 75% efficiency at 230VAC or 48VDC and full load. It provides a 48VDC input option as well and can be configured for the acquisition of output voltages from 0.5 to 62V. The input voltage range is 90 - 264VA and takes 11A of input current, while operating at 90VAC.
The TDK Lambda Vega 650 comes with excellent protection features, since it offers protection against shocks, short circuits, overload, and overvoltage conditions. This power supply has a holdup time of 16ms at 90VAC. The TDK Lambda Vega 650 power supply is approved by various safety agencies including, BSI, CE, EN, and CULus. This model is an ideal solution to be used in industrial computing, security, automation, as well as the instrumentation, broadcasting, and medical industries. The Vega 650 is a model which is known for its termination flexibility, modular construction, and looming options.
As far as its leakage current performance is concerned, this model operates with 1.5 mA max leakage current at 264 Vac & 63 Hz. The TDK Lambda Vega 650 offers <0.1% line regulation and <0.5% or 25mV load regulation for 0 to 100% load charge. It is designed to operate at <1% voltage accuracy and supports remote sensing as well. There is a 16A / 250Vac HBC Fast Acting input fuse provided for the equipment’s protection.
| Model | Vega 650 |
|---|---|
| Manufacturer | TDK Lambda |
| Series | Vega Series |
| Type | Power Supply |
| Input Voltage Range | 90-264VAC 47-63Hz |
| Input Current | 11A |
| Maximum Output Power | 650 W |
| Vega 650 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for Vega 650:
