Starpoint Aeroflex SP6010-0416 Wireless Communication Test Set
The StarPoint Aeroflex SP6010-0416 is a dedicated wireless communication test set designed for TD-SCDMA applications. The set identifies the instrument as a specialized platform for controlled RF generation and precise signal analysis. It runs on an embedded Windows XP Professional environment that supports integrated measurement software and stable system operation. The communication set provides defined RF ports that support transmitter and receiver evaluations under controlled conditions. The AUX A, AUX B and AUX C interfaces allow auxiliary RF routing for baseband and intermediate-frequency tasks within test workflows. The 10 MHz reference input and output maintain frequency discipline across external signal chains through a stable reference signal. A 5 ms trigger port enables deterministic timing between the instrument and external equipment.
The Aeroflex SP6010-0416 wireless set integrates LAN, USB and GPIB interfaces that support automated testing in industrial environments. The LAN port enables transport of control commands in structured network systems. The USB port offers access to removable storage for logs and automation scripts. The GPIB interface provides legacy support for established test benches that rely on standardized command sets and synchronized instrument control. The system display provides clear presentation of modulation characteristics and RF parameters for TD-SCDMA signals. The front panel combines function keys and a numeric control pad that enable structured navigation through measurement menus.
The SP6010-0416 showcases rotary encoder that supports incremental parameter adjustment during calibration or tuning procedures. The calibration label confirms that the unit supports traceable calibration routines for consistent RF measurement accuracy. The instrument maintains operational continuity in facilities that require certified test equipment. The rear panel houses a VGA connector that allows external displays during detailed signal analysis tasks. The wireless test set contains RS-232 style port that permits communication with compatible accessories for system configuration. The test chassis includes side handles that assist during installation and repositioning in space-limited lab environments. The StarPoint Aeroflex SP6010-0416 operates with defined cell power capability of -70 dBm. The reference input level supports up to 30 dBm which enables stable synchronization with external RF sources. These limits support predictable RF behavior during transmitter performance checks and receiver sensitivity evaluations.
| Model | SP6010-0416 |
|---|---|
| Manufacturer | Aeroflex (Starpoint) |
| Part Type | Wireless Communication Test Set |
| Supported Technology | TD-SCDMA 3G wireless communication standard |
| RF Reference Interface | 10 MHz reference input/output (BNC) |
| Auxiliary RF Ports | AUX A, AUX B, AUX C (BNC) for RF and IF routing |
| Trigger Interface | 5 ms trigger port for timing synchronization |
| Control Interfaces | LAN (Ethernet), USB, VGA, GPIB, serial-style service port |
| Front-Panel Controls | F1–F12 soft keys, measurement keys, numeric keypad, encoder knob |
| Physical Construction | Rack-mountable chassis with metal handles and structured port layout |
