Anritsu MP1650A Pulse Generator
The Anritsu MP1650A Pulse Pattern Generator is utilized with the MP1702A/1690A/1651A Error Detectors, separately. The amplitude of the clock and information signals can fluctuate from 0.5 to 2Vp-p while the counterbalance can be acclimated to inside +/ - 2V, so the amplitude and the counterbalance edge can be measured. The clock has a variable postpone work with the goal that time-subordinate attributes or phase edges of the input clock and data can be measured for any instrument. Also, a 3.5-inch floppy disk drive is worked in for storing preset information, enabling quick estimations to be performed by pressing a key. A GPIB function is given, allowing programmed or remote estimation by means of an external controller. The MP1650A is a Pulse Pattern Generator ideal for innovative work and Low FM/PM-noise Clock Generator.
This model has a frequency between 0.05 to 3 GHz and is capable of generating 512 KB prog. patterns and PRBS patterns. It has 8:1 Multiplexer operation, Complementary Data and Clock Output, a Precision N-Type connector, 524288 bits of Data Length, and 80 ps of Rise/Fall time. Among the performance characteristics, the MP1650A offers a Form Factor Benchtop, 8 Channels, a Frequency Accuracy of 0.001%, Maximum Output Voltage of 2 V, Output Data Memory Channel of 512 KB, an User Interface Proprietary, Type Pattern, a Minimum Pulse Width of 3 ns, an Output Data Format NRZ, and 50 Ohm of Output Impedance.
If you want to learn more about the MP1650A, the manual for this model is available on the ApexWaves.com website.
| Model | MP1650A |
|---|---|
| Manufacturer | Anritsu (Anritsu Kabushiki-gaisha) |
| Series | MP1650 Series |
| Type | Pulse Pattern Generator |
| Frequency Range | 0.05 to 3 GHz |
| Connector | N-type |
| Rise/Fall Time | 80 ps |
| Channels | 8 |
| MP1650A Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
