MP1763C
Anritsu Pulse Pattern Generator- 0.05 to 12.5 GHz frequency range
Actual item may vary if no part number is provided on quote request.
✔ 2 Year Warranty Included
✔ Free Domestic Ground Shipping
✔ NIST Calibration Available
Andrew Gar**** Verified Buyer
" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "
March 2025
Said Sai**** Verified Buyer
" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "
January 2025
Bob C**** Verified Buyer
" Jason was able to get our emergency situation taken care of quickly and professionally. "
May 2025
Gregg Flecki**** Verified Buyer
" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "
January 2025
Carol Zimme**** Verified Buyer
" Very responsive and helpful, competitive pricing. Good source! "
July 2025
Andrew Gar**** Verified Buyer
" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "
March 2025
Said Sai**** Verified Buyer
" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "
January 2025
Bob C**** Verified Buyer
" Jason was able to get our emergency situation taken care of quickly and professionally. "
May 2025
Gregg Flecki**** Verified Buyer
" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "
January 2025
Anritsu MP1763C Pulse Pattern Generator
The Anritsu MP1763C Pulse Pattern Generator is utilized in Error Detection for 12.5G BER testing. The amplitude of the clock and information signals might vary from 0.25 on 2 Vp-p at the same time the offset is adjusted inside ±2 v, so the amplitude and the offset margin can be estimated. The clock has a variable delay function, which causes the time reliant characteristics or phase margins of the input clock and data to be estimated. An M-series pseudorandom pattern representative of actual conditions or a programmable pattern can be designated as cell information. As new norms are settled upon, there will be a need to have the ability to support the assessment for units and circuits during higher bit rates. Toward this later stage, the Anritsu MP1763C can be used to support these older standards and data rates.
This model has 1/8 parallel output as standard and offers options accessible to a 1/4 parallel output or 1/4 differential output. This model represents the industry’s best 12.5G BERT framework for differential inputs. Also, the ¼ differential outputs are required for SAN market device applications. Additionally, this model incorporates a 3.5-inch floppy disk drive, which can be used to save preset data, empowering fast estimations to be performed by pressing a key. A GPIB interface is provided, empowering automatic or remote estimations through an outside controller. The MP1763C pulse pattern generator is perfect for research work and development of high-speed logic, ICs, and digital systems.
The manual for this model is available on the ApexWaves.com website.
| Model | MP1763C |
|---|---|
| Manufacturer | Anritsu Corporation (ã‚¢ãƒ³ãƒªãƒ„æ ªå¼ä¼šç¤¾ Anritsu Kabushiki-gaisha) |
| Type | Pulse Pattern Generator |
| Operation Frequency | 0.05 to 12.5 GHz |
| Outputs | 2 (DATA/DATA independently) |
| Rise/Fall Time | Typical 30 ps (10% to 90% of amplitude) |
| Amplitude | 0.25 to 2 Vp-p, 2 mV steps |
| MP1763C Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
