Haivision Makito B-290D-HD Video Decoder
The Haivision Makito B-290D-HD is a blade based video decoder for precise industrial automation workflows. The module supports compliant decoding operations that align with controlled processing environments. It uses optimized hardware logic that maintains stable operation under consistent automation loads. The video decoder provides defined decoding functions that meet structured system requirements. It supports a maximum resolution of 1920 x 1080 that is suitable for controlled monitoring tasks. The device maintains output integrity through one HDMI port that delivers stable digital video signals. The design includes an SDI output that enables direct serial digital routing to defined equipment.
The B-290D-HD decoder unit integrates audio line input that supports structured system level acquisition. It includes audio line output that maintains consistent delivery to external processing components. The module operates with certification under ISO and IEC standards specified for media processing. It supports ISO IEC 14496-10 and ISO IEC 13818-7 for controlled decoding performance. The video decoder also supports ISO IEC 14496-3 to ensure structured handling of defined audio streams. It handles MPEG-4 and MPEG-2 formats that appear in automation driven video pipelines. The system also supports H.264 and AVC formats that maintain stable compression compatibility in operations.
The device processes audio across a frequency range from 20 Hz to 22 kHz for consistent output quality. The video decoder also contains an RJ45 network interface that supports auto detecting Ethernet configurations. The unit operates on Ethernet 10/100/1000 Base T with selectable duplex modes. It supports static IP and DHCP addressing models. The unit provides a second RJ45 port that enables controlled LAN pass thru functionality. The B-290D-HD operates on 5V DC power and it consumes 13 W of power. It wires a stable blade form factor that fits structured rack level integrations. The system supports command line access over Telnet for structured administrative control tasks. The design includes optional RS 232 management that supports hardware oriented integration methods. The unit supports FTP and TFTP operations that maintain controlled firmware and configuration transfers. The Makito B-290D-HD ensures predictable behavior when handling continuous video streams in constrained automation spaces. The unit maintains defined behavior across continuous operation cycles that demand sustained hardware consistency. The device functions within predictable limits established by its certified decoding and audio processing capabilities.
| Model | B-290D-HD |
|---|---|
| Manufacturer | Haivision |
| Series | Makito |
| Part Type | Video Decoder |
| Power Requirement | 5 VDC, 13 W |
| Audio Frequency Range | 20 Hz to 22 kHz |
| Network Interface | RJ-45, Ethernet 10/100/1000 Base-T |
| Management Interfaces | HTTP, Telnet CLI, RS-232 (optional), FTP/TFTP |
| Supported Video Formats | MPEG-4, MPEG-2, H.264, AVC |
| Network Features | Auto-detect, half/full duplex, static IP/DHCP |
| Maximum Video Resolution | 1920 × 1080 |
