Hamamatsu C4742-95-12ERG Progressive Scan Interline CCD Camera
The Hamamatsu C4742-95-12ERG is a progressive scan interline CCD camera that is designed for precise optical performance supported by stable electronic cooling technology. It uses a fixed imaging element that ensures dependable capture. This model supports controlled imaging processes required in inspection and measurement environments to maintains consistent responsiveness when integrated with automated systems. The C4742-95-12ERG imaging module features a CCD element with 1344 x 1024 effective pixels. Its resolution supports detailed data acquisition required in structured analysis workflows. Each pixel measures 6.45 microns to support accurate signal formation across the sensitive surface. The sensitive area measures 8.66 mm x 6.60 mm which enhances spatial consistency to achieve stable output across its full imaging field.
The camera supports a frame rate of 8.3 Hz in standard mode. Its binning modes allow improved performance through 2 x 2, 4 x 4 and 8 x 8 configurations. These modes provide frame rates of 16 Hz 29 Hz and 45 Hz respectively. The binning process increases sensitivity by combining pixel charge at the CCD level to improve signal quality during low light operation and controlled image acquisition. The readout system of Hamamatsu C4742-95-12ERG module offers a 12-bit A to D conversion process for reliable digital output. Its mean readout noise is 8 electrons which supports consistent low noise imaging. The conversion coefficient is 4.6 electrons per count to maintain predictable signal scaling. The unit’s full load equals 18000 electrons before A to D overflow occurs. Its contrast enhancement gain ranges from 1 to 10 to support controlled signal adjustment.
This C4742-95-12ERG uses electronic cooling with air assisted dissipation to maintain stable temperature. Its cooling stabilization requires several minutes and ensures minimal thermal noise during operation. The C mount interface supports optical components used in industrial setups without modification. Its camera integrates smoothly with fixed mounting assemblies through its standardized mechanical layout and it uses a structured body. The power requirements of the CCD Camera progressive scan interline CCD imaging module include selectable inputs of 110/220 V and its operating frequency is 50/60 Hz which allows deployment across global facilities. The unit’s total power consumption is 90 VA. It comes with a structured architecture and defined resolution and pixel geometry that deliver consistent data quality for analytical applications.
| Model | C4742-95-12ERG |
|---|---|
| Manufacturer | Hamamatsu |
| Part Type | Progressive-scan interline CCD fixed imaging element |
| Power Consumption | 90 VA |
| Input Voltage | 110/117 VAC ±10% or 220/240 VAC ±10% |
| Cooling | Electronic cooling + air cooling |
| Frame Rate | 8.3 Hz |
| Resolution | 1344 (H) × 1024 (V) |
| Pixel Size | 6.45 µm × 6.45 µm square pixels |
| Sensitive Area | 8.66 mm × 6.60 mm (2/3-inch size) |
