National Instruments NI-9926 C Series Terminal Block

The National Instruments NI-9926 is a C Series Terminal Block that offers connectivity with a 10-Pin RJ50 back end connection and a 4-Pin Screw Terminal front end connection. This Terminal Block is a quarter-bridge completion block for RJ50 connectors designed for C Series modules. This Terminal Block is suitable for dusty and hot industrial environments. You can operate the NI-9926 within a temperature range of -40 °C to 70 °C. This C Series Terminal Block can be used for adding a quarter bridge to several National Instruments devices, such as the NI 9237.

The NI-9926 is a passive device, since it does not require additional power to operate. This Terminal Block weighs 1.1 oz. and is 2.6 in. × 0.85 in. × 0.90 in. The NI 9926 Terminal Block has design features that make it a suitable choice for high vibration applications. A provision for plastic tie straps is also available. Thus, you can ensure that the cables carrying power and signals will be held tight in the desired position.

The NI-9926 is a versatile accessory because it can be used in various environments and applications. However, it is an unshielded terminal block and can only be used in applications where shielded accessories are not deemed as mandatory. This Terminal Block comes with an internal, NI 1,000 Ω resistor. The resistor incorporated in the NI 9926 Terminal Block has a drift rating of 0.0100 Ω/°C and a resistor power of 0.25 watts maximum.
