TB-2715
Test & Measurement Misc > National Instruments > Terminal Blocks
| Description: | TB-2715, Screw Terminals, Terminal Block |
Need an Official Quote?
Or speak to a sales representative for additional information:
Phone:1-800-915-6216
Email:sales@apexwaves.com
National Instruments TB-2715 Terminal Block
The TB-2715 is a PXI Terminal Block. National Instruments designs the NI TB-2715 terminal block. The TB-2715 is a member of the TB Terminal Block Series by National Instruments. National Instruments produces the NI TB-2715 Terminal Block with the part number 778242-01. The TB-2715 Terminal Block is manufactured to be utilized with the NI PXI-653X, as well as NI PXI-660X devices. This Terminal Block is equipped with screw terminal connections for connecting to the compatible PXI modules.
The National Instruments TB-2715 Terminal Block is fabricated to be connected to the digital inputs/outputs of PXI modules. The TB-2715 Terminal Block provides smooth and tight connections as the screws get locked. The NI TB-2715 Terminal Block is equipped with a strain relief, which connects to the screw terminals of the front panel on PXI modules. The National Instruments TB-2715 Terminal Block can be installed on the front panel of the compatible PXI modules.
The National Instruments TB-2715 Terminal Block requires a few hardware accessories. The hardware includes wire cutters, a wire insulation stripper, a slotted 0.10 inch screwdriver, and a Number 1 Phillips screwdriver. The NI TB-2715 Terminal Block is equipped with an EMI Gasket and PXI module connector inside the enclosure. The TB-2715 Terminal Block is built with the dimensions of 3.32 by 4.1 by 0.8 inches. This Terminal Block is equipped with screw terminal connections.
TB-2715 Obsolete Status has been announced by National Instruments, but the Terminal Block will still be available for purchase and repairs by Apex Waves.
| Model | TB-2715 |
|---|---|
| Manufacturer | National Instruments |
| Part Number | 778242-01 |
| Type | Terminal Block |
| Compatible Modules | PXI-653X and PXI-660X |
| Connection Type | Screw Terminals |
| Dimensions | 3.32 by 4.1 by 0.8 in. |
| Warranty | 2-3 Year Warranty |
| TB-2715 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
Associated part numbers for the TB-2715:
187310A-01, 187310B-01L, 187310C-01L, 778242-01
