VIAVI T-BERD 5800 Handheld Modular Network Test Platform
The T-BERD 5800 is a handheld modular test unit that provides full support for SDH Fiber Channel and OTN service validation. The unit enables integrated workflows that improve multi technology testing. The platform performs automated RFC 2544 testing that ensures predictable throughput and latency performance. It applies SAM-Complete procedures for structured service activation tasks. This device maintains consistent accuracy through predefined profiles that validate critical traffic parameters. The unit includes advanced burst testing that aligns with MEF 34 requirements for controlled traffic analysis. It implements True-Speed testing that measures end to end TCP throughput values effectively.
The integrated timing/synchronization tests cover PTP SyncE Wander and One Way Delay. These functions verify clock stability under varied loading conditions that impact network precision significantly. The front-haul validation includes CPRI and OBSAI Layer 1 and Layer 2 procedures for diverse deployments. The tester is able to emulate both remote radio and baseband units for efficient field operations. The single port and dual port configurations allow flexible application across varied transport scenarios. It has compatibility with OTDR modules and Smart Link Mapper enhances fiber path analysis under field conditions. The T-BERD 5800 easily connects with both optical power meters and microscopes that extend overall optic diagnostic capability.
The network tester system supports BBU emulation that validates performance in distributed radio architectures used today. RFoCPRI capabilities enable evaluation of radio transport conditions that influence fronthaul efficiency significantly within integrated network environments. The layer 3 IPv4 support allows structured verification of routed services that operate on managed networks. The RJ-45 ports provide copper testing for 10BASE T, 100BASE T and 1000BASE T services. The SFP plus ports enable optical testing that ensures stable performance across diverse Ethernet transport links.
The VIAVI T-BERD 5800 supports symmetric throughput tests that validate upload and download performance under controlled conditions. Loopback measurements enable verification of bidirectional paths that require stable operational behavior. The local network settings support DIX frame types for accurate Layer 2 analysis in varied deployments. The VLAN encapsulation options appear when required so users can validate tagged service configurations reliably. VLAN ID input supports structured service workflows that follow work order specifications during field operations.
| Model | T-BERD 5800 |
|---|---|
| Manufacturer | VIAVI |
| Part Type | Handheld Modular Network Test Platform |
| Encapsulation Type | VLAN |
| Ports | RJ-45 ports |
| Frame Type | DIX |
| Ethernet Support | Dual 10G Ethernet testing capability |
| Burst Testing | Integrated burst testing per MEF 34 |
| Ports (Optical) | SFP+ optical interface testing |
| Compatibility | Works with OTDR modules, SLM microscopes, power meters |
Associated part numbers for T-BERD 5800:
