Anritsu MS2025B Network Analyzer
The Anritsu MS2025B Network Analyzer is a field-hardy, all-around instrument designed specifically for field engineers who need to make accurate RF measurements in industrial automation and wireless network-related situations. Based on Anritsu's advanced handheld design, the MS2025B enables full-range vector network measurement that supports the stringent S-parameter analysis of antennas, feedlines, cables, and filtering components with utmost precision. The 2-port measurement capabilities include the measurement of return loss, insertion loss, phase, and impedance, as well as other vital factors, thus supporting quality signal evaluation in challenging environments.
The MS2025B, with its wide frequency range of up to 4 GHz and as low as 500 kHz, delivers substantial benefit in the testing of modern communications systems. Its high sweep speed, combined with an optional select calibration, dramatically reduces the time needed for testing. In addition, its ability to make frequency domain measurements equivalent to distance domain data adds the accuracy needed for fault localization. Its advanced distance-to-fault capability allows technicians to quickly and efficiently locate cable breaks and diagnose issues with loose connectors, corrosion, or physical damage.
The instrument has an easy-to-use touchscreen interface and dynamic display settings that make complicated measurement easier, thus making fast field analysis possible. Additionally, the addition of marker functions, trace overlay, and limit line editing enhances its analysis efficiency, thus ensuring maximum efficiency in the detection of discrepancies in performances and system reliability. Various connectivity means, including USB, Ethernet, and the ability to integrate with GPS, enable efficient data logging, mapping, and real-time geographic tagging.
Engineered for reliable operation in demanding environments, the Anritsu MS2025B Network Analyzer combines critical measurement capabilities in one, portable instrument, thus doing away with the need for several different ones. It’s tough construct, simple configuration, and flexible properties enable the performance of operations concerning servicing, service debugging, and system verification. This new analyzer acts as an invaluable tool for industrial automation, telecommunications, and network infrastructure testers who improve on-site efficiency in real-world situations and ensure the long-term optimal operation of communications systems.
| Model | MS2025B |
|---|---|
| Model Type | VNA Master™ |
| # Ports | 2-Port |
| VNA Type | 1-Path VNA |
| Frequency Range | 500 kHz to 6 GHz |
| Measurement Type | S11, S21 |
| Sweep speed | 850 µs per Point |
| Calibration Stability | Up to 16 Hours |
| DTF Capability | Cable Fault Detection |
| Port Configuration | Dual-Port |
| RF Immunity Mode | High/Low Selectable |
| Interface | Touchscreen, Customizable Menus |
