Hioki 3541
Hioki 3541, 1 ms Analog Response Time, 30 VA, Milliohm HiTester
Actual item may vary if no part number is provided on quote request.
✔ 2 Year Warranty Included
✔ Free Domestic Ground Shipping
✔ NIST Calibration Available
Andrew Gar**** Verified Buyer
" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "
March 2025
Said Sai**** Verified Buyer
" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "
January 2025
Bob C**** Verified Buyer
" Jason was able to get our emergency situation taken care of quickly and professionally. "
May 2025
Gregg Flecki**** Verified Buyer
" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "
January 2025
Carol Zimme**** Verified Buyer
" Very responsive and helpful, competitive pricing. Good source! "
July 2025
Andrew Gar**** Verified Buyer
" Amazing to work with and had my order within 1 week after purchasing with all NI certs and data that were needed. "
March 2025
Said Sai**** Verified Buyer
" Competent contact for highly specialized components. The support team is very knowledgeable. Many thanks for the help and the fast shipping! "
January 2025
Bob C**** Verified Buyer
" Jason was able to get our emergency situation taken care of quickly and professionally. "
May 2025
Gregg Flecki**** Verified Buyer
" Great service and great products. This is my 2nd time using Apex Waves, truly impressed. "
January 2025
Hioki 3541 Milliohm HiTester
Featured with Comparator and BIN Functions, the 3541 is a Resistance HiTester from Hioki. This single instrument can be utilized for the measurement of extremely low to high resistances within a range of 0.1 μΩ to 110.000 MΩ. The integrated comparator on this model can compare measurements with predefined upper and lower limits. The Hioki 3541 can output the comparator judgment results via RS-232C, EXT I/O, and GPIB interfaces. These interfaces also allow seamless integration of the 3541 into automated production lines.
With this model, the user can save around 30 different sets of measurement conditions, including settings for BIN and comparator measurements. Each set can be saved and later recalled by selecting a setting number. The saved settings can also be accessed through remote controlling. The Hioki 3541 comes equipped with a multipolar connector (INPUT B). It is a low-thermo electromotive force connector with tremendous noise immunity. The INPUT B is a viable solution for high-speed and precise measurements of large resistances. This Resistance HiTester maintains consistent accuracy since it has a self-calibration function. The instrument undergoes a self-calibration cycle at every measurement, at power on, and when measurement conditions are changed.
A Windows based Personal Computer can easily control the Hioki 3541. The user can have every function accessed remotely, with the power switch being the only exception. For temperature correction, the user can utilize the 9451 Temperature Probe or an infrared thermometer`s analog output. For quality control and process analysis, the Hioki 3541 offers a broad range of statistical calculation functions as well.
| Model | Hioki 3541 |
|---|---|
| Manufacturer | Hioki |
| Type | Milliohm HiTester |
| Analog Response Time | 1 ms |
| Rated Power Consumption | 30 VA |
| Rated Supply Frequency | 50/60 Hz |
| Interfaces | GP-IB, RS-232C, EXT-I/O |
| Dimensions | 8.46 in × 3.15 in × 11.61 in |
| Weight | 91.7 oz |
| Hioki 3541 Manual | User Manual and Maintenance Manual Available for Download |
| Price | Contact a sales representative for a quote. |
